2. MARINE TOILET INSTALLATION

WARNING: Read and understand the warnings listed in this document before you
install, operate, or service this system. If you do not obey these warnings, there is a
risk of property loss, injury, or electrocution. Do not make any changes to this unit as
this could result in property damage, injury, or electrocution.
Tecma has no responsibility or liability for damages to equipment, injury, or death
that may result from the system's improper installation, service, or operation.
Tecma recommends that plumbing and electrical work be performed by a licensed
tradesperson. Local permit and code compliance is required.
WARNING: Danger of Electric Shock, Fire and Flooding. Failure to heed these
warnings can result in loss of property, injury and death.
WARNING:
inside the toilet.
HAZARD WARNING: Contact with moving part
ALWAYS disconnect power to the toilet before servicing. There is a serious injury risk by
placing hands/fingers in the bowl discharge because of the high-speed macerating
impeller located directly below the bowl discharge. NEVER attempt to dis-lodge an
obstruction in the pump by placing your hands/fingers in harm's way while it is running.
Always use ABYC-RECOMMENDED CIRCUIT BREAKER/FUSE AND WIRE GAUGE.
■
Always be sure unit's ELECTRICAL POWER is TURNED OFF and that SEACOCKS are
■
CLOSED or in the "OFF" position before beginning work.
If Toilet is connected to any through-hull fittings, ALWAYS CLOSE or TURN OFF ALL
■
SEACOCKS when BOAT IS UNATTENDED – even if only for a minimal time.
For units using fresh water that are (at any time) connected to shore side municipal
■
water supply systems, SHORE SIDE SYSTEM must be DISCONNECTED IF BOAT IS LEFT
UNATTENDED – even if only for a minimal time.
If unit is connected to any through-hull fittings, ALL flexible tubing connected directly
■
or indirectly between toilet and ANY through-hull fitting must be of marine quality and
must be connected to each fitting with TWO (2) STAINLESS STEEL WORM DRIVE HOSE
CLAMPS. These HOSE CLAMPS must be INSPECTED FREQUENTLY TO ENSURE
TIGHTNESS, thereby preventing leaks.
If unit is connected to any through-hull fittings, PROPERLY INSTALLED SEACOCKS
■
MUST BE INSTALLED to these lines. All seacocks (or secondary valves fitted in
connecting, intermediate tubing) MUST BE FULL-BORE VALVES and READILY
ACCESSIBLE to all toilet users. Use lever-actuated, full-bore, marine quality seacocks
and valves. Screw-down gate valves are not recommended.
Tecma S.r.l.
Via Flaminia | Loc. Castello delle Formiche
05030 Otricoli (TR)
ITALY
Do not leave children unattended to use the toilet. Do not put body parts
Compact line | Installation and use manual | ENG
