3.2

Raw water considerations

The Raw Water pump must be securely mounted in a dry, well-ventilated area. It
■
should be mounted not more than 6' at any time above the heeled waterline.
DANGER: The Raw Water pump must be powered by the toilet relay module. Use of
any pump that draws more than 15 amps requires installation of a pump contactor
relay. Do not wire pump directly to a D.C. power source so that it is controlled by its
pressure-activated switch. If a leak were to occur when wired directly, the pump
would run continuously and create risk of sinking of the boat and loss of life.
■
An in-line strainer MUST be installed to protect the system. Failure to use an in-line
strainer may void product warranty.
■
A Vented Loop of proper diameter MUST be installed if – UNDER ANY
CIRCUMSTANCE or CONDITION (including heel trim or load):
• Toilet is connected to a through-the-hull fitting and rim of toilet could
DANGER: Failure to use a Vented Loop in raw water pump installation sites can lead
to water flowing into the toilet from the outside (siphoning)
which can cause loss of property and life!
3.3

Required tools

■
1-1/4" hole saw
■ 3-1/2" hole saw
■ saber saw
■ 7/16" socket and ratchet or 7/16" wrench
■ Electric drill
■ 1/8" drill bit
Tecma S.r.l.
Via Flaminia | Loc. Castello delle Formiche
05030 Otricoli (TR)
ITALY
EVER be in a position below the waterline.
