English
BEFORE CUTTING
1. Cutting a groove on the table insert
Table Insert
Vise (A)
Fig. 7
2. Checking the saw blade lower limit position
Up
Fig. 8
3. Securing the workpiece
WARNING:
4. Installing the holders (Standard accessory)
Holder
Fig. 9
12
A groove has to be cut in the table insert, before starting opera-
tion. Secure a piece of wood about 5" (125 mm) wide to the turnta-
Turntable
ble with the vise (A), to prevent the breakage of the table insert.
After the switch has been turned on and the saw blade has reached
its maximum speed, slowly lower the handle to cut the piece of
wood, and then a groove on the table insert.
CAUTION:
Check that the saw can be lowered 1 - 1/4" to 1 - 5/16" (32 mm to
33 mm) below the table insert.
If necessary, adjust as follows:
10mm Depth
(1) Loosen the 10mm lock nut on the 10mm depth adjustment bolt.
adjustment bolt
(2) Turn the 10mm depth adjustment bolt as necessary to set the
lower limit position. The saw blade goes up when the 10mm
depth adjustment bolt is turned counterclockwise and down
when it is turned clockwise.
Down
(3) Once the adjustment is complete, fully tighten the 10mm lock
nut.
NOTE:
Always clamp or vise to secure the workpiece to the fence; otherwise the workpiece
might be thrust from the table and cause bodily harm.
The holders help keep longer workpieces stable and in place dur-
ing the cutting operation.
Install them on the right and left sides of the base and fix them
with 10 mm bolts.
For moving the holders, loosen the 10 mm bolts.
10 mm Bolt
Do not cut the groove too quickly; otherwise the
guard might become damaged.
Before tightening the 10mm lock nut, confirm that the
saw blade is adjusted so that it will not cut into the turn-
table. Allow a space of 3/16" (4 - 5 mm) between the saw
blade and the turntable.
