Safety information
Safety information
The following symbols are used in this manual and on your device:
Symbol Signal word Meaning
Danger Warning message regarding risk of injury or
health risk.

Important

Safety note on possible damage to the device /
accessories
Note Note regarding important information.
Danger Small parts can be swallowed by children!
0 - 36 M
Warning Use hearing protection when testing the wire-
less smoke detector!
Battery recommendations
A battery change is not necessary and technically impossible because the device
must not be opened!

Functions

To ensure correct operation of device, please observe the following points:
• Do not cover the device!
• Do not paint or cover device with wallpaper!
• Do not open or attempt to repair the device under any circumstances.
Non-observance of the above points will render the guarantee void.
• The device is rendered unsuitable for use once it has been dropped or any other
damage has been suffered.
– 30 –

Technical data

• Power supply
• Smoke detection
• Visual operating display
• Electric consumption
• Operating temperature
• Storage temperature
• Air humidity
• Sound pressure
• Alarm mute mode
• Detection range
• Installation location
• Wireless frequency
• Wireless range
• Networking
• Battery service life
• Dimension
• Maximum transmission power
• Applied standards
Technical data
DC 3 V Lithium Battery (built-in)
photoelectric reflection
LED flashes approx. every 6 minute
9,8 mA (ø standby) || 80 mA (ø alarm)
0° to 45° C
-10° to 60° C
10 % to 90 % (non-condensing)
> 85 dB (A)@3 m
ca. 11 minutes
max. 40 m² within a single room
ceiling (internal rooms only)
868 Mhz
at least 100 m
Up to 12 detectors
Up to 2 years
Height 36 mm, Diameter 102 mm
10 dBm
EN14604, VdS 3131, VdS 3515
– 31 –
