7. Align the drawer glides with the slides on the inside of the
cabinet. Insert the drawer glides into the slides and push the
drawer into the cabinet.
NOTE: If the drawer glide is not correctly aligned with the cabinet
slide, the drawer may become lodged in the cabinet. Facing the
cabinet, press down on the lever located on the right-hand
drawer glide while pressing up on the lever located on the left-
hand drawer glide to release the drawer.
8. Once each drawer is in place, work from the rear of the cabinet to
completely tighten the six screws (3 on each side) attaching the
drawer back.
D2
D2
D2
A. Tighten drawer screws

Attach Lower Back Panel

F3b Phillips-head screw (5 - black)
1. Using Phillips-head screws (F3b), attach the lower back panel
(P6) to the bottom (P4) and sides (P1 and P3) as shown. Tighten
screws completely.
2. Using the Allen wrench (provided), completely tighten all the
cabinet bolts and nuts.
P6
A
P2
P1
F3b
P2
D2
P1
D2
D2

Attach Upper Back Panel

F3b Phillips-head screw (9 - black)
1. Align back panel (P5) with the holes in the top (P2). Using
Phillips-head screws (F3b), attach back panel (P5) to the top (P2)
and sides (P1 and P3) as shown. Do not tighten screws
completely.
NOTE: Back panel (P5) will slightly overlap back panel (P6)
2. Using Phillips-head screws (F3b), attach the upper back panel
(P5) to the lower back panel (P6) as shown.
3. Completely tighten all back panel screws starting with the sides
and continuing with the top, middle, and bottom.
P5

Complete the Assembly

1. Make sure there is a bolt or screw in each hole of the cabinet
frame.
NOTE: Not all the holes in the cabinet side panels will be used.
2. Move the cabinet to its final location.
3. Place a level on the cabinet top, and if necessary, level the
cabinet by adjusting the height of the leveling legs (P7). Turn to
the left to raise or to the right to lower the leveling leg.

ACCESSORIES

To order accessories, call 1-866-342-4089 and ask for the accessory
part number listed below or contact your authorized Gladiator brand
dealer. In Canada, call 1-800-807-6777.
Caster Kit
Order Part # GACK04KDSX
VersaTop™ Work Surface
Order Part # GAVT18SPSX
