Front panel

1
1. [PHONES] output jack
2. [PHONES VOLUME] knob
3. [VIDEO SELECT] switch

Rear panel

1
1. Power switch
2. Power connector
3. [MIDI IN], [MIDI OUT] connectors
4. [CONNECTION] switch
5. [NTSC/PAL] switch
2 3 4 5
4
2 3 6 7
4. [INPUT 2] S-video jack
5. [INPUT 2] video jack
5
8
9
6. [OUTPUT] S-video jack
7. [OUTPUT] video jack
8. [OUTPUT] audio jacks
9. [INPUT] video jack
10. [INPUT] audio jacks
