Connecting the monitor:
1. Connect the cord of the 5VDC adaptor to the "power supply" plug of the monitor (the
BATT indicator turns green).
2. Plug the adaptor into a 230 VAC mains socket
3. Use without adaptor:
Lithium battery with 4-hour battery life.
- The battery indicator turns on if the battery is low
- The indicator turns off if the battery is full.
CAUTION
6

FUNCTION AND USE OF THE KIT

a. Commissioning
Press the key of the monitor (use these same keys to turn it off).
b. Connecting the cameras
1. Connect the cord of the 5VDC adaptor to the "Power supply" input of the camera.
2. Plug the adaptor into a mains socket.
3. Use without adaptor: Lithium battery with 4-hour battery life
Battery indicator: - Green LED
c. Associate the camera to the monitor
For the first use, the camera included in the kit is already paired. If not or to add another
camera, proceed as follows:
Press the « OK » key of the monitor and go to the "PAIR CAM" menu of the monitor with
the q key.
Select a free channel between 1, 2, 3 and 4 with the t and u keys.
Press the key to start recording.
You have 60 seconds to pair the camera, to do so, press the « Link » button on the side of
the camera.
Only one channel per camera can be activated on the monitor.
In the case of several cameras, you must choose 1 different channel for each camera.
8GB
Only place the monitor on stable and hard surfaces.
- Red LED
- LED OFF
