WARNING
All work on the cutting means (disassembly, 
sharpening, balancing, repairing, reassembly 
and/or replacing) are demanding jobs that 
require special skills as well as special tools; 
For safety reasons, these jobs are best 
carried out at a Authorised Service Centre.
ATTENTION
Always use original cutting means bearing 
the code indicated in the "Technical Data".
NOTE
Given product evolution, the cutting means 
listed in the "Technical Data" table may be 
replaced in time with others having similar 
interchangeable and operating safety features.

9.3 REPLACING FRONT / REAR WHEELS

9.3.1 Preliminary operations
DANGER
Use a suitable lifting device.
Before changing the wheels it is necessary 
to complete some preliminary operations:
1. Position the machine on a solid 
and even surface that guarantees
stability of the machine.
2. Stop the machine;
3. Remove the key from the ignition;
4. Position the lifting device in the
lifting position near the wheel to be 
changed (par. 9.3.2; par. 9.3.3).
5. Check that the lifting device is perfectly 
perpendicular to the ground.
9.3.2 Choice and positioning of the
jack on the rear wheels
1. Position some wooden wedges (fig. 25.A) 
at the base of the wheel (fig. 25.B) next 
to the wheel to be changed (fig. 25.C).
2. The maximum possible jack height 
when closed is 130 mm. (fig. 26).
3. Position the jack under the rear plate (fig. 
27.A) at 180 mm from the side edge (fig. 26).
NOTE
In this position the jack allows you to 
raise only the wheel to be changed.
9.3.3 Choice and positioning of the
jack on the front wheels
1. Position some wooden wedges (fig. 28.A) 
at the base of the wheel (fig. 28.B) behind 
the wheel to be changed (fig. 28.C).
2. The maximum possible jack height 
when closed is 170 mm.
3. Place on top of the jack (fig. 29.A) a 
squared piece of wood (fig. 29.B) having 
a cross-section of about 5 x 2 cm.
ATTENTION
The thickness of the wood prevents 
damage to the front axle.
4. During this stage, keep the wooden 
pad balanced on the jack with one 
hand. Lift the jack making sure that the 
wooden pad rests against the frame 
and the structural parts (fig. 29.C).
NOTE
The jack positioned in this way makes it 
possible to lift the entire front axle.
9.3.4 Changing the wheel
SAFETY INSTRUCTION
Make sure that the machine remains still 
and stable during the lifting process. If you 
notice anything out of the ordinary, lower 
the jack immediately, check and resolve 
any problems and lift the machine again.
1. Remove the cover (fig. 30.A).
2. Raise it enough to extract the wheel easily.
3. Use a screwdriver to remove 
the snap ring (fig. 30.B) and the 
shoulder washer (fig. 30.C).
4. Remove the wheel to be changed.
5. Smear the axle (fig. 30.D) with grease.
6. Mount the spare wheel.
7. Carefully replace the shoulder 
washer and snap ring.
NOTE
Check that the two rear wheels are the same 
height (fig. 31.A) and that the difference 
between the external diameters of the 
two wheels (fig. 31.B) is no greater than 
8-10 mm. On the contrary, to avoid uneven 
mowing, the cutting means assembly must be 
aligned by an Authorised Service Centre.
EN - 24
