PDC 18/4 Li
GB
LED green – flashing slowly:
charged 30 % – 60 %
LED green – flashing quickly:
charged 0 % – 30 %
LED yellow – lit continuously:
battery is empty
LED red – lit continuously: bat-
tery temperature is outside the
permitted range.
LED red – flashing: indicates a
general fault, e.g. incomplete
contact, short circuit, battery
pack faulty, etc.
7 Settings
CAUTION
Risk of injury
Always switch off the power tool before adjusting
settings!
7.1 Changing direction of rotation [1-9]
• Switch to the left = clockwise rotation
• Switch to the right = counterclockwise rotation
7.2 Changing gear
You can change gear using the gear switch [1-7].
7.3 Adjusting the torque[1-8]
Fastening
Select the correct torque setting:
Position 1 = low torque
Position 12 = high torque
An acoustic signal sounds when the preset torque
is reached and the machine then switches off. You
must release and press the ON/OFF switch [1-4]
again to start the machine.
Drilling
Mark is aligned with drill symbol
torque.
7.4 Impact drilling
The machine was designed for impact drilling
into tiles, masonry and stone.
Set the selector switch [1-6] to the hammer sym-
bol. Set the adjusting wheel [1-8] to the drill sym-
bol.
12
8

Tool holder, attachments

Risk of injury
Always disconnect the battery pack before per-
forming any type of work on the machine!
Hot and sharp tools
Risk of injury
Do not use insert tools that are blunt or defec-
tive.
Wear protective gloves.
Prior to initial use: apply multi-purpose grease
to the drill spindle and gearbox neck.
8.1 CENTROTEC tool chuck [4]
Quick change of tools with CENTROTEC shaft
Only clamp CENTROTEC tools in CENTRO-
TEC tool chucks.
Wear gloves when replacing!
8.2 Chuck [5]
For clamping drill bits and bits with max. shaft di-
ameter of 13 mm.
Clamp tool centrally in the chuck.
8.3 Angle attachment [6]
Drilling and screwdriving at right angle to machine
(partly as an accessory).
8.4 Tool holder in the drill spindle [7]
Bits can be inserted directly into the hexagon sock-
et holder of the drill spindle.
8.5 Depth stop [8]
The depth stop (partly as an accessory) allows the
user to insert screws to a predefined depth. You can
= maximum
set the dimension by which the screw head pro-
trudes above or is recessed below the surface of the
workpiece.
Depth setting
Sleeve A/B must be removed before a screw can be
unscrewed.
WARNING
CAUTION
Turn the housing [8-1] to set the
desired fastening depth. Each
detent position changes the fas-
tening depth by 0.1 mm.
