Set alignment for the rear wheels:
The alignment for the rear wheels is set by the
so-called tie-in-block. This is a plastics part (A)
screwed to the back of the differential.
The two metal axles holding the lower trans-
verse links are attached to the outer holes of
the toe-in block.
A toe-in block with a different distance between
these two holes can be used to adjust the toe-
in of the rear wheels.
The delivery includes a plastics part with additional toe-in blocks; see the
figure on the right.
The toe-in setting for the rear axle has little effect on driving
behaviour. Therefore, toe-in block replacement will only be
important for professional drivers.
