Beyerdynamic MCS 50 Notice D'utilisation page 38

5. Parameter
Warning time
More
Reset N.o.m.
6 sec.
- +
Reset N.o.m.
6. Parameter
NOM
More
Reset N.o.m.
2
- +
Reset N.o.m.
7. Parameter
Prior button
More
Reset N.o.m.
Mute
Clear
Reset N.o.m.
Clear
Mute
Reset N.o.m.
Note Configuration with MCS-Editor
(refer also to page 38 "Chairman mode"):
Function "Normal": Chairman microphone unit is switched on, delegate microphone unit is switched off. The delegates can switch on their
microphone unit again immediately.
Function "Clear": Chairman microphone unit is switched on, delegate microphone unit is switched off and remains switched off as long as
the chairman is speaking.
38
In this menu the warning time is adjusted i.e. the time between which the illuminated ring starts flashing and
the time when the microphone is switched off.
The warning time (in this example 6 seconds) only operates when the talk time allowed has been previously
adjusted. Use the left (4) or right (5) button for adjusting.
In this menu the number of the open delegate microphone units (NOM) can be adjusted. This adjustment can
be checked by pressing the right button (5) at any time. The adjustment should be performed according to the
acoustical conditions of the location.
In the example the NOM has been entered with "2". Use the left (4) or right (5) button to enter the number.
In this menu the function of the priority button of the chairman microphone unit can be adjusted.
The present adjustment is shown in the top line. Pressing the left button (4) the adjustment is changed.
Mute: Pressing the priority button of the chairman microphone unit the chairman can mute all
activated delegate microphone units while he is talking. When the priority button is switched
off again, all previously switched on microphones are re-activated.
Clear: The chairman can switch off all activated delegate microphone units with the priority button.
