7 Installation instructions

7.2 Electrical connection

Only an authorised service technician may connect the appliance.
The connection must comply with national and local requirements.
The appliance must always be earthed.
The appliance comes with a supply cable which must be supplied with a connector. Refer
to the table below:
Blue
blauw
If you want to make a fi xed connection, make sure that a multi-polar switch with a contact
separation of at least 3 mm is fi tted in the supply line.

7.3 Building-in

Please check the minimum measures necessary to the proper
installation of the appliance. The espresso machine must be
installed in a column unit, which must in turn be fi xed to the
wall.
136
Brown
bruin
Green/yellow
geel/groen
N
L
230V
8 0 m
m i n
m m
5 6 0 m
5 5 0
m
5 0 m
.
m i n
m i n
8 0 m
m
m i n .
m
.
m
.
