Connecting / Disconnecting

Connecting
■
A Turn the computer off.
Do not connect the Mini Port
Replicator in sleep
(
Windows Vista
Windows XP
mode.
B Connect the Mini Port
Replicator to the connector of
the computer with Panasonic
logo facing upwards.
E
(For information about the position of the Expansion Bus
Connector, refer to the computer's Operating Instructions.)
C Tighten screw (A) until the waterproof sheet goes out of sight.
When using the computer in unstable
D
places such as a car, or when using the
computer with the Mini Port Replicator
attached continuously, attach the rubber
caps to prevent the screws from
loosening.
Tuck the rubber caps in until there is no
gap between the screw base and rubber.
Disconnecting
■
A Turn the computer off.
Do not disconnect the Mini Port
Replicator in sleep (
standby (
mode.
B Remove the rubber caps.
C Loosen screw (A).
D Pull the Mini Port Replicator out straight.
6
) / standby (
) or hibernation
Windows Vista
) or hibernation
Windows XP
Expansion Bus
Connector
A
Waterproof sheet
) /
A
