3. Installation
NOtICE
The interplay between racing shell and adapter is
crucial to how the entire seat system behaves.
„ Mount the RECARO Pro Racer SPG XL HANS
and RECARO Pro Racer SPA XL HANS
racing shells only with the independently
tested RECARO adapters 7207450A (SPG
XL HANS), 7207000A (SPA XL HANS) or
7206293.
3.1. Positioning the racing shell in the vehicle
„ Select the most comfortable seat position for
yourself that is safest for driving the vehicle:
You must be able to completely hold the top
edge of the steering wheel without lifting yourself
out of the seat with your back.
When the clutch or brake pedal is fully pressed,
your knee should still be slightly angled.
„ Make sure that the restraint systems and the roll
cage are correctly installed (see the manufac­
turer's installation instructions).
3.2. Scope of delivery (Figures A and B)
„ Check the scope of delivery for completeness
before installation
Racing shell
(1) Racing shell, 1 ea.
(2) Seat cushions, 1 ea.
(3) Rest cushion, 1 ea.
Flexible adapter 7206293 (Figure A)
(4) Flexible adapter, 1 ea.
(5) Screw M8x20, 10.9, 4 ea.
(6) Washer, 4 ea.
Rigid adapter 7207450A and 7207000A
(Figure B)
(7) Adapter, 2 ea.
(8) Screw M8x20, 10.9, 4 ea.
(9) Washer, 4 ea.

3.3. Installation sequence

Refer to Page 3 for the associated draw-
ings.
Alignment of the rigid adapters 7207450A and
7207000A
NOtICE
On each of the insides of the two adapters there
is a black arrow on a white background
„ Mount the adapter in the vehicle so that the
arrows point in the driving direction.
The arrow must point in the driving
direction.
Alignment of the flexible adapter 7206293
NOtICE
„ Mount the adapter in the vehicle so that the
length adjustment lever points in the driving
direction.
Mounting adapters in the vehicle
NOtICE
The adapters must be secured in the vehicle
and the associated structural modifications to
the vehicle must be done in accordance with the
stipulations of the DMSB or the FIA as per the
respective applicable version of the regulations
that apply.
„ Mount the adapters (4) or (7) in the vehicle with
four M8 screws, strength class 10.9. Tightening
torque: 35 Nm.
Fixing the racing shell (Figures C and D)
1. Position the racing shell (1) between the
adapters (4) or (7).
2. With the adapter (4) or (7), set the seat height by
selecting the rear holes (a, b).
3. Fix the racing shell at the rear to the adapters (4)
or (7) with the washer (6) or (9) and the M8x20
screw (5) or (8). When doing this, only tighten
the screws hand­tight.
