6. Spare parts

Clamping screws
similar DIN 913
similar DIN 913
similar DIN 913
Length adjustment screws

7. Technical Data

Chuck Max. Permissible
diameter speed transferable
smallest size,
lubricated shank)
mm rpm
6 50 000
8 50 000
10 50 000
12 50 000
14 50 000
16 50 000
18 50 000
20 50 000
25 25 000
32 25 000
12
Size
M 8 x 10
M 10 x 12
M 12 x 14
Size
M 5 x 12,5
M 6 x 12,5
M 8 x 1 x 12,5
M 10 x 1 x 12,5
M 12 x 1 x 12,5
M 16 x 1 x 12,5
Minimum Length of
chucking
torque depth
(shank h
6
Nm mm
12 27
20 27
38 31
75 36
98 36
160 39
200 39
280 41
400 47
650 51
Key size
s4
s5
s6
Key size
s2,5
s3
s4
s5
s6
s6
Permissible
traverse radial force F temperature
l on chuck at
3
50 mm overhang
mm N
10 225
10 370
10 540
10 650
10 900
10 1410
10 1580
10 1860
10 4400
10 6500
Order No.
415 720
415 718
415 719
Order No.
415 136
415 137
415 138
315 733
415 139
315 734
Operating Max.
coolant
pressure
C° bar
20 - 50 80
20 - 50 80
20 - 50 80
20 - 50 80
20 - 50 80
20 - 50 80
20 - 50 80
20 - 50 80
20 - 50 80
20 - 50 80
Shank
dia.
mm
6
h6
8
h6
10
h6
12
h6
14
h6
16
h6
18
h6
20
h6
25
h6
32
h6
