Invacare DBA Instructions De Montage Et D’utilisation page 2

Towards The
Front Of Chair
Assembly of
hooks for 1-inch
(25mm) drop (use
holes as indicated)
MAINTENANCE
These instructions MUST BE followed:
1. Clean weekly with warm water and mild soap
solution. Wipe entire surface with a soft, clean cloth.
2. Visually inspect all parts weekly for deformation,
corrosion, breakage, wear and/or compression.
3. Check hook and loop fasteners for adhesion and
engagement.
Hook And Loop
Faces UP
hooks for 3-inch
Assembly of
hooks for 2-
inch (50mm)
drop (use holes
as indicated)
FIGURE 1 - ASSEMBLY
Towards The
Rear Of Chair
Assembly of
1-inch (25mm), 2-inch (50mm) and 3-
(75mm) drop
(use holes as
indicated)
DO NOT continue to use this product if any
such problems are discovered. Corrective
maintenance can be performed at or
arranged through your equipment supplier.
2
Drop Base Assembly for
inch (75mm) drop
(use holes as indicated)
WARNING
