If you obtain aid please give the following infor-
mations:
1. Where did it happen
2. What happend
3. How many injured
4. Type of injury
5. Who is reporting!

6. Technical data

Engine
Transmission
Load capacity
Box Length
Box width
Box Depth
Weight
Engine Type
Idle speed
maximum RPM
Motor Starters
Unleaded fuel octane num-
Fuel ber 90 and max. ethanol of
5%
Fuel tank capacity
Required engine oil
max. slope
Max. Oil tank capac-
ity
Subject to techcnical modifications!
Information concerning noise emission measured ac-
cording to relevant standards:
Sound pressure L = 84,7 dB(A)
pA
Sound power L = 100 dB(A)
wA
Uncertainty K = 3,0 dB(A)
pA
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Vibration Left Steering Lever A
Vibration Right Steering Lever A
Uncertainty K = 1,5 m/s
2
PA
The specified vibration emission value has been
measured according to a standardised testing proce-
dure and can be used for comparison of one electric
tool with another.
The specified vibration emission value can also be
used for an initial assessment of the load.
m WARNING
The vibration emission value can vary from the spec-
ified value during the actual use of the electric tool,
depending on the type and the manner in which the
electric tool is used.
Try to minimise stress from vibrations as low as pos-
sible. Some examples of means for reducing the vi-
bration stress are wearing gloves while using the
tool and limiting work time. In the process all parts
of the operating cycle must be taken into account
(such as times in which the electric tool is switched
off or time in which it is switched on, but is not run-
ning under a load).
24 I 60
 www.scheppach.com  service@scheppach.com  +(49)-08223-4002-99  +(49)-08223-4002-58
6,5 PS
3F+1R
300 kg
912 mm
650 mm
560 mm
160 kg
4-stroke engine
3000 1/min.
3600 1/min.
Recoil starter
3,6 l
SAE 10W-30
12°
0,6 l
= 3,92 m/s
2
hv
= 9,92 m/s
2
hv
Limit the noise and vibration to a minimum!
• Use only faultless device.
• Maintain and clean the unit regularly.
• Customize the way you work on the equipment.
• Do not overload the device.
• If you unsure, bring the device to a service station
• Switch off the unit if you do not use it.

7. Before starting up

m ATTENTION!
Always check before starting the engine:
• Check the fuel level and top it up if necessary
- the tank (21) should be at least half filled
• Make sure that the machine has sufficient ventila-
tion
• Make sure that the ignition cable (25) is secured
to the spark plug (13)
• Condition of the air filter
• Condition of the fuel lines
• The external bolt connections for tightness
Filling with fuel
Recommended fuel
Fill the only clean fuel with min. 90 octane and max.
5% bio-ethanol content in the fuel tank (21).
m NOTE
Fill tank to no more than 12.5mm (1/2") below the
bottom of the filler neck to provide space for ex-
pansion.
Use only fresh and clean fuel.
m Attention!
Water or impurities in the petrol damage the fuel sys-
tem.
Tank volume: 3,6 litre
m Refuel in a well-ventilated area with the
stopped engine. If the engine has been running,
allow it to cool first. Never refuel the engine in-
side a building where gasoline fumes may reach
flames or sparks.
Petrol is highly flammable and explosiv. You can
get burns or other serious injuries when handling
fuel.
• Switch off the engine and keep it away from heat,
sparks and flames.
• Refuelling only outdoors.
• Immediately clean up spilled petrol.

8. Functions and controls

Engine switch (Fig.1/Pos.2)
The engine switch (2) enables and disables the igni-
tion system.
The engine switch (2) must be in the "ON" position
for the engine to run.
The engine switch (2) must be in the "OFF" position
to stop the engine.
