Attaching The Auxiliary Handle - Black & Decker EASYFEED BESTE620 Mode D'emploi

Fig. C

Attaching the Auxiliary Handle

(Fig. D, E, F)
• To attach the handle
both sides of the upper housing as shown in figure D.
• Position the handle as shown in figure E, matching
up the grooved side of the handle with the grooved
button. Partially push the handle on so that it will hold
the buttons in when you release them with your hand.
• Push the handle completely onto the housing and
position it slightly until it "snaps" into place (Fig. F).
• To adjust the handle up or down, press in on the
button and raise or lower the handle.
13
• The handle should be adjusted so that your front arm is
straight when the trimmer is in the working position.
Fig. D
13
Fig. E
5
5 , press in on the buttons
Fig. F
Height Adjustment (Fig. G)

CAUTION: Adjust the length of the trimmer to obtain
13 on
proper working positions as shown in figure I3.
• The overall height of the trimmer can be adjusted by
loosening the collar
the arrow shown in figure G.
• Move the upper housing straight up or down. When the
desired height is achieved, tighten the collar by rotating
it opposite of the direction shown in figure G.
Fig. G
Attaching Extension Cord (Fig. H)
An extension cord retainer
that prevents the cord from coming unplugged.
• To use this feature, simply double the extension cord
about 8" (203 mm) from the end, and insert it into
the slot
14
figure H.
• Hook the loop formed by doubling the cord over the
tab 27 . Gently tug on the cord to ensure that it is firmly
retained in the trimmer's handle.
• Plug the receptacle end of the extension cord into the
power cord plug
6 and rotating it in the direction of
6
3 is built into the switch handle
in the end of the handle area as shown in
in the trimmer.
4
English
13
5
