English
Cleaning

WARNING: Blow dirt and dust out of all air vents with
clean, dry air at least once a week. To minimize the risk
of eye injury, always wear ANSI Z87.1 approved eye
protection when performing this.

WARNING: Never use solvents or other harsh
chemicals for cleaning the non-metallic parts of
the tool. These chemicals may weaken the plastic
materials used in these parts. Use a cloth dampened
only with water and mild soap. Never let any liquid
get inside the tool; never immerse any part of the tool
into a liquid.

Accessories


WARNING: Since accessories, other than those
offered by BLACK+DECKER, have not been tested with
this product, use of such accessories with this tool
could be hazardous. To reduce the risk of injury, only
BLACK+DECKER recommended accessories should be
used with this product.

WARNING: The use of any accessory not
recommended by BLACK+DECKER for use with this
trimmer could be hazardous.

CAUTION: Before you begin trimming, only use the
appropriate type of cutting line.
Use BLACK+DECKER replacement spool Model No. AF-100,
and replacement cap RC-100.
Reload nylon line (either bulk or prewound replacement
spool) as shown in this manual.
• USE ONLY .065" (1.65 mm) DIAMETER ROUND NYLON
LINE. Do not use serrated or heavier gauge line, as
they will overload the motor and cause overheating.
This line is available at your local dealer or authorized
service center.
• Other replacement parts (guards, spool caps, etc.) are
available through BLACK+DECKER service centers. To
find your local service location call: 1-800-544-6986 or
visit www.blackanddecker.com.
Replacing the Spool (Fig. M—P)

WARNING: To reduce the risk of serious personal
injury, turn unit off and disconnect it from
power source before making any adjustments or
removing/installing attachments or accessories.
An accidental start-up can cause injury.
• Unplug trimmer.
• Depress the tabs 15
from the spool housing
(Fig. M).
8
and remove the spool cap
16 in the trimmer head
Fig. M
• For best results, replace spool with BLACK+DECKER
model no. AF-100.
• Grasp empty spool with one hand and spool housing
with other hand and pull spool out.
• If lever
17
dislodged, replace in correct position before inserting
new spool into housing.
Fig. N
• Remove any dirt and grass from the spool and housing.
• Unfasten the end of the cutting line and guide the line
into the eyelet
Fig. O
21
• Take the new spool and push it onto the boss
the housing (Fig. N). Rotate the spool slightly until it is
seated. The line should protrude approximately 5-3/8"
(136 mm) from the housing.
• Align the tabs on the spool cap with the slots
housing (Fig. P).
21
16
(Fig. N) in base of housing becomes
18
19
17
19 (Fig. O).
15
19
in
18
20 in the
