Lean Top Plate (1) as shown and pre-install Washers (21) and Hex Bolts (18) (Figure A).
1
Next lay Top Plate as shown on flat surface or table with Hex Bolt (21) pointing up (Figure B).
18
21
Hardware: (4x) 5/16"-18 x 2-1/4" Hex Bolt, (4x) 5/16" USS Washer
Place Hitch Assembly (2) over bolts (18) and install Washers (21) and Hex Nuts (20) as
2
shown in the Front and Back holes.
Hardware: (2x) 5/16"-18 Nyloc Hex Nut, (2x) 5/16" USS Washer
Attach Center Plate (6) over middle Hex Bolts (18) with Washers (21) and Hex nuts (20).
3
Orient flange of Center Plate (6) away from knobs (5) on Drawbar. Tighten all hardware at
this time.
2
Hardware: (2x) 5/16"-18 Nyloc Hex Nut, (2x) 5/16" USS Washer
Assembly Instructions
1
Figure A
Front & Back Hole
20
21
5
6
18
Figure B
2
20
21
18
Suggested Tools: 1/2" Wrench and 1/2" Socket
Correct
Suggested Tools: 1/2" Wrench and 1/2" Socket
4
21
18
Wrong X
