Warning!
The continuous­feed shredder must be
completely assembled before use. Never
assemble the continuous­feed shredder on
the base unit. Operate the continuous­feed
shredder in the indicated operating position
only.
Predetermined breaking point
Fig. F:
The built­in predetermined breaking point
protects the drive of the appliance. If an
overload occurs, the drive shaft of the
c ontinuous­feed shredder breaks. However,
the drive shaft can easily be replaced. A new
disc holder with drive shaft is available from
customer service.
Reversible slicing disc –
thick / thin
for slicing fruit and vegetables.
Process at setting 5 (3).
Designation on the reversible slicing disc:
"1" for the thick slicing side
"3" for the thin slicing side
Warning!
The reversible slicing disc is not suitable for
slicing hard cheese, bread, rolls or choco­
late. Slice boiled, waxy potatoes only when
they are cold.
Reversible shredding disc –
coarse / fine
for shredding vegetables, fruit and cheese,
except for hard cheese (e.g. Parmesan).
Processing at setting 3 (2) or 4 (3).
Designation on the reversible shredding disc:
"2" for the coarse shredding side
"4" for the fine shredding side
Warning!
The reversible shredding disc is not suitable
for shredding nuts. Shred soft cheese with
the coarse side only at setting 7 (4).
Grating disc – medium-fine
for grating raw potatoes, hard
cheese (e.g. Parmesan), cooled chocolate
and nuts.
Process at setting 7 (4).
Warning!
The grating disc is not suitable for grating
soft cheese and cheese slices.
Working with the continuous-feed
shredder
Fig. G:
■ Press the Release button and
move the swivel arm to position 2.
■ Insert the bowl:
Tilt the bowl forwards and then set
it down. Turn anti­clockwise until it locks
into place.
■ Press the Release button and
move the swivel arm to position 3.
■ Remove drive cover from the
drive of the continuous­feed shredder
(Fig. G-5a).
■ Hold disc holder at the lower end, ensuring
that the two tips are face up.
■ Carefully place the required slicing or
shredding disc onto the tips of the disc
holder (Fig. G-6a).
In the case of reversible discs, ensure that
the required side is face up.
■ Grip disc holder at the upper end and
insert into the housing (Fig. G-6b).
■ Attach the cover (note mark) and turn all
the way in a clockwise direction.
■ Place continuous­feed shredder on the
drive and rotate all the way in a clockwise
direction, as illustrated in Fig. G-8.
■ Turn rotary switch to recommended
setting.
■ Put food to be processed in the feed tube
and push down with the pusher.
Warning!
Prevent the cut ingredients from building up
in the outlet opening.
Tip: To ensure even cutting results, process
thin ingredients in bunches.
Note: If the food to be processed sticks in
the continuous­feed shredder, switch food
processor off, pull out mains plug, wait until
the drive comes to a standstill, remove cover
from the continuous­feed shredder and
empty feed tube.
