Specifications
Monitor
Specifications
Diagonal:
LCD Module
Viewable Image Size:
Native Resolution (Pixel Count):
Video:
Input Signal
Analog input:
Display Colors
Left/Right:
Viewing Angle
Up/Down:
Horizontal:
Synchronization
Vertical:
Range
Resolutions Supported
Resolution based on horizontal and
vertical frequencies only
Horizontal:
Active Display Area
Vertical:
Power Supply
Current Rating
Dimensions
Weight
Environmental Considerations
Operating Temperature:
Humidity:
Storage Temperature:
Humidity:
*
1
Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may
appear different. This is normal and necessary for all current flat panel technologies when displaying non-native
resolutions full screen. In flat panel technologies, each dot on the screen is actually one pixel, so to expand resolutions to
full screen, an interpolation of the resolution must be done.
2
*
The number of colors displayed that can be decreased.
NOTE: Technical specifications are subject to change without notice.
LCD1830.wpc
MultiSync
LCD
®
1830
Monitor
18.1 inch
18.1 inch
1280x1024
ANALOG 0.7 Vp-p/75 Ohms
Sync:
Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. Positive/Negative
Sync on Green (Video 0.7p-p and Sync 0.3V p-p)
16,777,216
± 80°
± 80°
24 kHz to 82 kHz
55 Hz to 85 Hz
720 x 400*
at 70 Hz
1
640 x 480*
1
at 60 Hz to 85 Hz
800 x 600*
1
at 56 Hz to 85 Hz
832 x 624*
1
at 75 Hz
1024 x 768*
1
at 60 Hz to 85 Hz
1152 x 864*
at 75Hz
1
1152 x 900*
1
*
2
at 66Hz
1280 x 960*
*
at 60Hz to 75Hz
1
2
1280 x 1024 at 60 Hz to 76 Hz ................. optimal display performance.
359 mm/14.1 inches
287 mm/11.3 inches
AC 100 - 120V
/220–240 V
@ 50/60 Hz
0.8 A @ 100–120 V, 0.4 A @ 220-240 V
435 mm (W) x 449 mm (H) x 215 mm (D)
17.1 inches (W) x 17.7 inches (H) x 8.5 inches (D)
8.5 kg
18.7 lbs
5°C to 35°C/41°F to 95°F
30% to 80%
Feet:
0 to 12,000 Feet
-10°C to 60°C/-14°F to 140°F
10% to 90%
Feet:
0 to 53,300 Feet
12
14
Notes
™
Active matrix; thin film transistor (TFT)
liquid crystal display (LCD); 0.28 mm dot
pitch; 200cd/m
2
white luminence;
300:1 contrast ratio, typical
Depends on display card used.
Automatically
Automatically
Some systems may not support
all modes listed.
NEC-Mitsubishi Electronics Display cites
recommended resolution at 60 Hz for
Dependent upon signal timing used,
and does not include border area.
