Specifications
Monitor
Specifications
Diagonal:
LCD Module
Viewable Image Size:
Native Resolution (Pixel Count):
Video:
Input Signal
Analog input:
Display Colors
Horizontal:
Synchronization
Vertical:
Range
Resolutions Supported
Horizontal :
Active Display Area
Vertical :
USB Hub
Load Current:
Practical Audio Output:
Speakers
Power Supply
Current Rating
Dimensions
Weight
Environmental Considerations
Operating Temperature:
Humidity:
Storage Temperature:
Humidity:
*
Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
1
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each
dot on the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE: Technical specifications are subject to change without notice.
MultiSync
®
LCD
Monitor
15.0 inch
15.0 inch
1024 x 768
ANALOG 0.7 Vp-p/75 Ohms
Sync:
Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
16,777,216
31.5 kHz to 60 kHz
56.2 Hz to 75.1 Hz
720 x 400*
1
: VGA text
640 x 480*
1
at 60 Hz to 75 Hz
800 x 600*
1
at 56 Hz to 75 Hz
832 x 624*
at 75 Hz
1
1024 x 768 at 60 Hz to 75 Hz .................. NEC-Mitsubishi Electronics Display cites
304 mm/12.0 inches
228 mm/9.0 inches
I/F:
USB Specification Revision 1.1
Port:
Upstream 1
Downstream 4
Maximum 0.5A per port
1.0W + 1.0W
AC 100 -
120 V/ 220-240 V
0.75 A @ 100–120 V, 0.45 A @ 220-240 V
345 mm (W) x 363 mm (H) x 162 mm (D)
13.6 inches (W) x 14.3 inches (H) x 6.4 inches (D)
4.9 kg
10.8 lbs
5°C to 35°C/41°F to 95°F
30% to 80%
Feet:
0 to 10,000 Feet
-10°C to 60°C/14°F to 140°F
10% to 85%
Feet:
0 to 31,500 Feet
13
™
Notes
1550M
Active matrix; thin film transistor (TFT)
liquid crystal display (LCD); 0.30 mm dot
white luminence; 450:1
pitch; 300cd/m
2
contrast ratio, typical
Depends on display card used.
Automatically
Automatically
Some systems may not support
all modes listed.
recommended resolution at 75 Hz for
optimal display performance.
@ 50/60 Hz
