No. Description
1
Door drive unit/release: Make
2
Fault: Control unit: Open contact
3
Door contact: Contact setting depending on lock (trip latch) and input
X13
4
Cylinder contact: Contact switches when cylinder is actuated
5
Bolt contact: Contact switches immediately with mFlipLock bolt
6
Door handle contact: Door handle contact left switches immediately
7
External handle coupled: Door handle contact opposite to escape
direction switches when coupled and with e-access handle status
displayed on the right
8
Outputs
9
LED status inputs
10
Inputs
11
Factory settings: Terminals 16 and 15 bridged
12
External door contact (Reed): Monitoring contact (open)
manufacturer´s recommendation (bolt protection function)
13
External timer day/night/Office function: mFlipLock/FlipLock perma-
nent door release without activation TA(X1), flip latch released.
14
Locked: All inputs are inactive. mFlipLock locked.
15
Motorised unlocking: Unlocked/flip latch released. Input only active
when Day mode or DAY TA(X1) has 1.5-s impulse
16
External timer day/night/Day mode: Couple door handle in opposite
direction to escape direction.
17
Impulse button: Bolt will be retracted by 70%, flip latch blocked.
18
Access control (reader): Impulse present = coupling in time. Door
handle coupled in opposite direction to escape direction
19
Impulse button/Unlock impulse: Unlocked, flip latch released. Impulse
and permanent release. TA(X1) controlled as long as Impulse input is active.
20
Access control (reader): If DIP 5 ON and DIP 6
OFF, then TA(X1) 1.5 s
21
External timer for day/night/Impulse and timer: e.g. by introducing a
TA(X1) 1.5-s impulse DIP 5 ON /6 OFF
22
Key switch: e.g. door drive unit Fresh Air/Office function DIP 5/6 OFF
23
DIP 2 OFF = operating current (closed when deenergised)
DIP 2 ON = closed-circuit current (open when deenergised)
24
Reserve
25
6-pin connection cable LIYY 2x2x0.22 + 2x0.5 MSL item 10/20 m
14471403/04
26
DIP switch functions (separate operating instructions AWS, page 8)
27
Service button: Function (separate operating instructions for AWS,
page 14)
Assembly
All manuals and user guides at all-guides.com
No. Description
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
Jumper JP3: Factory setting item 1
Item 2. 120 Ω on RS485 X16 with terminating resistor if data bus faults
occur
Jumper setting JP4: Factory setting item 1
Item 2. 120 Ω on RS485 X16 with terminating resistor if data bus faults
occur
Finger scanner: (RS 485 BUS)
MOD BUS: WAGO node (RS 485 BUS)
Output supply: as well as X15 without S1
Fuse and LED: Function (separate operating instructions for AWS, pages
8 and 12)
Supply: 11–27 V DC +/- 10%
BMZ: Fire alarm input. Fire control system
LED status outputs
Evaluation control system (AWS) V1.1
Door drive unit = TA
LED status outputs
Fault
Door
Jumper setting item 1: 1 jumper in the middle. 24 DC/AC must be
present on terminals 38 and 39 for operation. (Triggered on loss of
voltage)
Jumper setting item 2: 2 jumpers one above the other. Terminals 38
and 39 must be bridged for operation. If the BMZ is triggered, then
these bridges must be separated by the BMZ (factory setting)
Cylinder
Bolt
Door handle in escape direction (e-access door handle left)
Door handle opposite to escape direction (e-access door handle right)
Door contact
Office function
Locked
Radar
Day mode
Impulse
GND
LED mode: Flashes when faults occur
Connection for mFlipLock
EN
