8
EXTERNAL REMOTE ON/OFF
Connect GND and ON/OFF (relay contact, switch, sensor, ..) allow control isolated outputs
with external signal.
Follow step for modifying configuration :
→
→
open switch => ON output(s) ; connect switch => OFF output (s)
9
USB CONNECTION
Preparation of communication :
Download on our website
Connect the power supply to the USB2.0 PC port with a USB cable
as A / B type USB (its length shouldn't exceed 5 meters).
Install the file.
Your PC is ready to communicate with the ALR3206D.
Use "Hyper Terminal ®" simple utility to communicate via the serial
port, present on all PCs with Windows 95®, 98®, XP®, Seven®.
If you wish to control the power supply by LabVIEW® the drivers and executable are to
be requested at commercial@elc.fr.
4000 4 360_09/22
Resistor mode
(Configuration
POTENTIOMETER)
A N A L O G R E M O T E
I N 2
I N 1
C H 2 ( V )
C H 1 ( V / A )
o r C H 1 ( A )
c o m m a n d
c o m m a n d
→
→select
Connection of
switch
A N A L O G R E M O T E
I N 2
C o m m a n d e
O N / O F F
www.elc.fr
26
Potentiometer mode
(Configuration
POTENTIOMETER)
A N A L O G R E M O T E
I N 2
I N 1
C H 2 ( V )
C H 1 ( V / A )
o r C H 1 ( A )
c o m m a n d
c o m m a n d
to
→
I N 1
the file : ALR32xx.inf
Voltage control mode
(Configuration
VOLTAGE)
A N A L O G R E M O T E
I N 2
I N 1
0 - 1 0 V
0 - 1 0 V
C H 2 ( V )
C H 1 ( V / A )
o r C H 1 ( A )
c o m m a n d
c o m m a n d
ENGLISH
