3. Inside the Robot
RESET Button
Network Setup: Press the RESET Button and follow the voice prompt to set up
the network�
Restore to default settings: Press and hold the RESET button for 5 seconds, and
you will hear a prompt sound� After that, the startup music will play, and the robot
will be restored to default settings�
Wi-Fi Status Indicator/
RESET Button
Charging Contacts
Water Filling Port
4. Mopping Pad Assembly
Mopping Pad Plates
5. Dust Bin
Filter
EN 10
6. Station Front View
Dirty Water Tank
Power Switch
"I" = ON
" " = OFF
Dust
Collection Cabin
Charging
Contacts on Station
Edge Sensor
Note:
• If the Indicator flashes red, go to the ECOVACS HOME App for details about the
malfunction�
• If the robot cannot charge, wipe the corresponding charging contacts on the
OMNI station with a dry cloth�
Washable Mops
7. Dust Bag
Dust Bag Handle
Dust Disposal Port
Release Button
Clean Water Tank
Indicator
Mop Washing Tray
