HIGH RATE SAND FILTER SYSTEM
AT11523, AT11823, AT12023, AT11526, AT11826, AT12026
AT11524, AT11824, AT12024, AT11525, AT11825, AT12025
AT11521, AT11821, AT12021, AT11522, AT11822, AT12022
AT11533, AT11833, AT12033, AT11536, AT11836, AT12036
AT11534, AT11834, AT12034, AT11535, AT11835, AT12035
AT11531, AT11831, AT12031, AT11532, AT11832, AT12032
AT11843, AT12043, AT11846, AT12046
AT11844, AT12044, AT11845, AT12045
AT12041, AT12042, AT11544, AT11840
AT12040
AT12037
AT121536
Aquatools
293 Wright Street, Delavan, WI 53115
North America: 800-752-0183, FAX 800-582-2217
International: 262-728-5551, FAX: 262-728-4461, TELEX: ITT 4970245
© 2005
All manuals and user guides at all-guides.com
For Above Ground Swimming Pools
O W N E R ' S
INSTALLATION, OPERATION & PARTS
System Series Number
M A N U A L
839 0494
Pump No.
Horsepower
AT2407110
3/4
AT2407130
3/4
AT2407122
3/4
AT2410110
1
AT2410130
1
AT2410122
1
AT241501
1-1/2
AT241503
1-1/2
AT2411122
1-1/2SPL
AT2024
1-1/2
AT2408541
1SPL
AT2608610
1SPL
This manual should be furnished to the end user
of this system; its use will reduce service calls and
chance of injury and will lengthen system life.
Pump Parts
On Page:
15
15
16
15
15
16
15
15
16
15
16
16
