WARNING Ensure the locking pin that blocks the vertical movement
of the blade (picture 22) is properly inserted in the lock position prior
to make a cut.
Do not use cracked or broken diamond blades.
Do not use side pressure to slow the cutting blades down.
The feed should be proportional to the cutting capacity of the blade.
This ensures that no material detachment occurs that could cause
accidents or injuries.
A. TO MAKE A STRAIGHT CUT
(Picture 26)
Adjust the angle guide to the desired width, and secure it in place.
angle guide and fence.
Ensure that the material does not touch the cutting blade before
Allow the cutting blade to reach its maximum speed and wait for
towards the blade.
move the sliding table towards the cutting blade.
cutting blade to stop completely before removing any part of
the material.
B. TO MAKE AN ANGLE CUT
(Picture 27)
Laser line can be used to quickly align the cut path with the
marks or cut lines on the tile
Adjust the angle guide to the desired angle using the scale and
With the angle guide at the desired width, secure it in place.
Ensure that the material does not touch the cutting blade before
Allow the cutting blade to reach its maximum speed and wait for
towards the blade.
towards the cutting blade.
to stop completely before removing any part of the material.
C. TO MAKE AN L CUT
(Picture 28)
corner, around an electrical or inspection box, or a piece of moulding,
and it is achieved by means of two separate cuts.
Laser line can be used to quickly align the cut path with the
marks or cut lines on the tile
Setup to cut the material to the desired width using the instructions
for the straight cut.
Using a marker or pencil, mark the lines to cut on the material.
Adjust the angle guide to the desired width, and secure it in place.
guide and fence.
Ensure that the material does not touch the cutting blade before
Allow the cutting blade to reach its maximum speed and wait for it
to become wet before moving the sliding table towards the blade.
move the material to be cut towards the cutting blade.
Make the cut to the marked length, without cutting excessively.
round to cut along the other marked line.
to stop completely before removing any part of the material.
D. TO MAKE A MITER CUT
(Picture 29)
Bevel cuts of 22.5° and 45° can be made by tilting the cutting head.
Move the sliding table to the user's work position so that the cutting
head can rotate without the blade interfering with the table.
Release the locking lever located at the rear of the cutting head
and tilt the cutting head to the desired angle, and re-lock the locking
The 0° and 45° position is set at the factory. If it is maladjusted,
see the Adjustments section of this manual.
before starting to cut.
Do not place the cutting head at an angle other than
0°, 22.5°, or 45º, as the blade could damage the sliding table and
injure the user.
Place the angle guide in the appropriate position according to the
width of the tile to be cut.
the angle guide.
When the tile is located to the right of the cutting head, it must
be placed face down for an outside miter cut.
to reach its maximum speed and wait for water to arrive at the cooling
to stop completely before removing any part of the material.
E. TO MAKE A PLUNGE CUT
(Picture 30)
To make square cuts in the center of the tile for electrical sockets or
inspection boxes, use the plunge function.
Laser line can be used to quickly align the cut path with the
marks or cut lines on the tile
Mark the lines of the area to be cut with a pencil or marker.
Release the cutting head by removing the locking pin and loosening
the locking knob.
Ensure the cutting depth limiter located at the top of the
cutting head is properly adjusted to prevent cutting too deep and
damaging the table.
Locate the tile in the center of the table with the visible side
upwards and align the marks with the cutting blade.
to reach its maximum speed and wait for the water to arrive at the
Lower the cutting blade to the tile without cutting further than the
marked line.
Repeat the process on the other marked lines.
This saw has been set in the factory to make accurate cuts.
Nevertheless, some of the components may have become misaligned
during transport. Also, with the passage of time, readjustment will
likely be required due to wear.
To guarantee the SAFETY and RELIABILITY of the product, repairs,
maintenance and adjustment (including the inspection and
replacement of the brushes) must be carried out by an authorised
identical spare parts.
When carrying out maintenance use only original spare
the product.
It is important to clean the saw frequently.
During use, the angle guide and other saw components get dirty,
preventing them from sliding smoothly.
Unplug the machine before carrying out any adjustments, repairs or
maintenance.
Do not use aggressive cleaning products to clean the machine. Only
use mild soap and a damp cloth for cleaning.
Do not submerge the machine in water.
- 9 -
