Transmitter
controls
6
1 Transmitter antenna
2 LC display
3 Rotary Controller 1
MODELS A & V: Travel limit for Function Channels 1, 2 & 4
4 Rotary Controller 2
MODEL A: Flaperon/fowler flaps
MODEL V: Aileron travel
MODELS H, C & C1: Pitch travel
For Aircraft Models H, C and C1, Rotary Controllers 1 and 2
can be used to adjust the pitch curve.
Both rotary controllers can be locked with the LOCK slide
switch.
5 Toggle Switch 1, Function Channel 5 (available) for supple-
mentary functions
6 Toggle Switch2 (3D switch for aerobatics)
MODEL A: Simulaton of fowler flaps
MODEL V: Supplementary functions
MODELS H, C & C1: Idle running with the throttle/pitch control
lever in mid-position
WARNING! When Models H, C or C1 are selected, you may
only switch into 3D operation while the gas/pitch lever is
in the mid-position.
7 Toggle Switch 3, dual-rate Function Channels 1, 2 & 4
Reduction of Functional Travels 1, 2 and 4 from 100% (Pos. 0)
to 70% (Pos. 1)
8 „MODEL" pushbutton for selecting the aircraft model
desired
9 LED (green) indicates the switching status
10 LED (red) indicates undervoltage
Replace the rechargeable batteries for the transmitter as soon
as the red LED begins to blink, or when the LCD display goes
off
11 Remote control lever (Function Channels 3 and 4)
12 Remote control lever (Function Channels 2 and 1)
Both remote control levers can be extended by approx 5 mm.
13 Trim Function Channel 3
14 Trim Function Channel 4
15 Trim Function Channel 2
16 Trim Function Channel 1
17 Ring for carrying strap
18 On/Off switch
WARNING! With MODELS H, C or C1 are preselected, the 3D
switch (Toggle Switch 2) has to be on „NOR" when the trans-
mitter
19 LOCK slide switch for locking the rotary controllers and the
MODEL pushbutton
20 Reverse switch, Function Channels 1, 2, 3, 4 & 6
Bottom: NOR (normal), top: REV (reverse)
21 Handle
22 Transmitter quartz (Rear side of the transmitter)
23 Connector socket for flight simulator
24 (rechargeable) battery compartment
25 Charging socket (Side of the transmitter)
CARSON 6 Channel Transmitter 501000
at the very latest.
is switched on.
