DK2 POWER OPV425 Mode D'emploi page 37

No. Description
1 Engine
2 Key
3 Clutch Assembly
4 Conical Washer
5 Lock Washer
6 External Hexagon Bolt
19 Locked Nut
22 Washer
39 Belt
40 External Hexagon Bolt
41 Large Washer
PARTS & SCHEMATICS
CLUTCH AND BELT
Qty.
x1
x1
x1
x1
x1
x1
x8
x8
x2
x4
x4
Specification
CH270
5 x 40
128 x 20
8 x 30 x 6
Ø8
M8 x 30
M8
Ø8
A-737
M8 x 45
8 x 30
v.211220 | 37
