OPERATION
MAINTENANCE
CHANGING THE V-BELT
WARNING:
attempting to change the V-belt. Changing the V-belt while the unit is still operating
will cause injury.
1.
Turn off the engine.
Loosen, but DO NOT remove the four nuts (40) that hold the engine (01) to the engine
2.
support plate (32).
3.
Using a nut (33) and bolt (34), slide the engine (01) towards the driver pulley (13 in Vibratory
Housing Assembly) until the belt (39) can be removed.
4.
Remove the old belts, then install new ones.
5.
Check the alignment of the two pulleys (side by side - in the same level/surface)
Using nut (33) and bolt (34), slide engine (01) away from the driver pulley (13 in Vibratory
6.
Housing Assembly) until belt is properly tensioned.
7.
Re-tighten the four nuts (40) that hold the engine (01) to the engine support plates (32).
30 | OPV425 man.
Check that the plate compactor engine is turned off and cooled before
