OPV425 17” x 21” PLATE COMPACTOR 4,750 VPM FREQUENCY • 17” x 21” PLATE • 7 HP KOHLER® ENGINE USER MANUAL DK2 USA WEST DK2 CORPORATE HEAD OFFICE DK2 USA EAST 4301 S VALLEY VIEW BLVD. 5330 MAINWAY 3750 SOUTH AVENUE,...
Page 3
TECHNICAL SPECIFICATIONS TECHNICAL SPECIFICATIONS ENGINE Kohler CH270 • 7 hp • 4,000 rpm • Command Pro Commercial 2.8 in BORE 70 mm 2.1 in STROKE 54 mm 12.7 in DISPLACEMENT 208 cc 0.63 U.S. qt OIL CAPACITY (REFILL) 0.60 L 0.030 in SPARK PLUG GAP 0.76 mm...
Page 5
SAFETY SAFETY CONVENTIONS CONVENTIONS USED IN THIS MANUAL WARNING: This indicates a hazardous situation, which, if not avoided, could result in death or serious injury. CAUTION: This indicates a hazardous situation, which, if not avoided, could result in minor or moderate injury. NOTICE: This information is important in proper use of your machine.
Page 6
éviter d'éventuelles blessures. LEVEL ATTENTION OIL LEVEL! NIVEAU D'HUILE! WARNING: HAND AND FOOT CRUSH ZONE Keep hands and feet away from vibrating plate at all times. Failure to follow this instruction could result in serious injury. 6 | OPV425 man.
Page 7
SAFETY SAFE PRACTICES & GENERAL INFORMATION WARNING: Read the Safety & Operations sections before you use the machine. Become familiar with the operation and service recommendations to ensure the best performance of your machine. CAUTION: This machine is designed solely to compact and must not be used for any other purpose.
Page 8
Keep in mind that the operator or user is responsible for accidents or hazards occurring to other people, their property, and themselves. • Always wear protective goggles or safety glasses with side shields while using the Compactor to protect your eyes from possible thrown debris. 8 | OPV425 man.
Page 9
SAFETY SAFE PRACTICES & GENERAL INFORMATION • Avoid wearing loose fitting clothing or jewelry, which can catch on moving parts. • We recommend wearing gloves while operating the machine. Be sure your gloves fit properly and DO NOT have loose cuffs or drawstrings. •...
Page 10
Also check engine mounting bolts. • Never tamper with safety devices. Check their proper operation regularly. • Before performing any maintenance or inspection procedure, shut down the engine, 10 | OPV425 man.
Page 11
SAFETY SAFE PRACTICES & GENERAL INFORMATION disconnect the spark plug wire keeping it away from the spark plug to prevent accidental starting, wait 5 minutes for machine to cool down. • Never allow people who are unfamiliar with these instructions to use the machine. Allow only responsible individuals who are familiar with these rules of safe operation to use your machine.
Page 13
OPERATION OPERATOR ZONE OPERATOR ZONE KEEP CLEAR OF THE RED NOTICE: Clear area around planned operating location. WARNING Never allow yourself or others to reach or step to the side or the front of the Compactor when it is running. This is very unsafe and could cause personal injury or death. v.211220 | 13...
Page 14
Pull Starter • Pull Tight, Then Pull Start Oil • Fill to mark with 10W30, will not start if oil is low, has low oil shut-off protection. Two yellow caps are oil fill caps, use either one to fill oil. 14 | OPV425 man.
Page 15
OPERATION SPECIFIC OPERATION WARNINGS WARNING • Only trained personnel are permitted to operate the compactor. • DO NOT operate under the influence of drugs or alcohol. • DO NOT operate in the presence of explosives or flammable substances such as liquids, gases, or dust.
Page 16
Check all the bolts, nuts, and belts. Tighten any if necessary. Check the general condition of the plate compactor and its components. Clean any foreign material (dirt, fragments, etc.) from the unit that may have been thrown off, causing injury. 16 | OPV425 man.
Page 17
OPERATION HANDLE ASSEMBLY WARNING: Read and understand both the engine and plate compactor’s manuals before starting or operating the unit to avoid incorrect operation that may result in damage or injury. Loosen the knob handle on each side of the upper handle. Swing the upper handle until it points straight out from the lower handle.
Page 18
NOTE: If the oil level in the engine is low, the engine will not start. If it doesn’t start, add oil to the engine. Some engines are equipped with an oil alert light that will come on while pulling the starter rope. Open the choke as the engine warms (b2). Open the throttle fully to operate. 18 | OPV425 man.
Page 19
OPERATION STARTING THE ENGINE NOTE: Whenever high-speed operation (over 3,600 RPM) is NOT required, slow the engine by moving the speed control lever to a low position to save fuel and extend the life of the equipment. Once the engine has started, firmly grasp the plate compactor’s handle bar with one hand then quickly turn the throttle lever to high speed.
Page 20
Slow the engine to idle by turning the accelerator lever fully counter-clockwise. • Shift the engine ON/OFF switch to the OFF position. • Close the fuel valve. See the engine’s owner’s manual for further information about your engine. 20 | OPV425 man.
Page 21
OPERATION AFTER EACH USE After your equipment has been unused for longer than 20 days, prepare the engine for storage with the following process: STEP 1: CLEAN Wait for the engine to cool, then clean the engine with a dry cloth. NOTE: DO NOT CLEAN USING WATER.
Page 22
Drain the fuel tank and change to fresh fuel if the untreated gasoline has been sitting for a month. If treated gasoline has been sitting beyond the fuel stabilizer’s recommended time period, or if the engine does not start, follow the steps starting on p.23. 22 | OPV425 man.
Page 23
OPERATION ENGINE START-UP (AFTER STORING FOR LONG PERIODS OF TIME) STEP 5 • 1: MOVE THE COMPACTOR WITH WHEEL STEP 5 • 2: FILL OIL INTO THE ENGINE v.211220 | 23...
Page 24
OPERATION ENGINE START-UP (AFTER STORING FOR LONG PERIODS OF TIME) STEP 5 • 3: CHECK THE OIL LEVEL STEP 5 • 4: FILL GASOLINE INTO THE FUEL TANK 24 | OPV425 man.
Page 25
OPERATION ENGINE START-UP (AFTER STORING FOR LONG PERIODS OF TIME) STEP 5 • 5: TURN OFF (LEFT) THE AIR VALVE CHOKER BEFORE STARTING THE ENGINE, AFTER ENGINE START, TURN IT BACK ON (RIGHT). STEP 5 • 6: BEFORE STARTING THE ENGINE, PLACE THE THROTTLE LEVER ON THE LEFT POSITION.
Page 26
OPERATION ENGINE START-UP (AFTER STORING FOR LONG PERIODS OF TIME) STEP 5 • 7: TURN ON THE RED SWITCH SHOWN BELOW STEP 5 • 8: START THE ENGINE 26 | OPV425 man.
Page 27
OPERATION ENGINE START-UP (AFTER STORING FOR LONG PERIODS OF TIME) STEP 5 • 9: MOVE THE THROTTLE LEVER TO YOUR LEFT v.211220 | 27...
Page 28
OPERATION ENGINE STOPPING STEP 6: STOPPING THE ENGINE STEP 6 • 1: MOVE THE THROTTLE LEVER TO YOUR RIGHT STEP 6 • 2: TURN OFF THE RED SWITCH SHOWN BELOW 28 | OPV425 man.
Page 29
OPERATION MAINTENANCE WARNING: Before performing any maintenance procedure or inspection, stop the engine, wait five minutes to allow all parts to cool. Disconnect spark plug wire, keeping it away from the spark plug. Disconnect the battery terminals (electric start only). REGULAR MAINTENANCE CHECKLIST PROCEDURE LEGEND...
Page 30
Using nut (33) and bolt (34), slide engine (01) away from the driver pulley (13 in Vibratory Housing Assembly) until belt is properly tensioned. Re-tighten the four nuts (40) that hold the engine (01) to the engine support plates (32). 30 | OPV425 man.
Page 32
PARTS & SCHEMATICS FULL SCHEMATICS Specification Specification Engine Belt Cover Clutch Assembly Bottom Plate Lower Handle Engine Support Plate Upper Handle Vibrator Unit Throttle Line Assembly Belt Handle Damper 32 | OPV425 man.
Page 33
PARTS & SCHEMATICS BASE PLATE Description Qty. Specification Large Washer 12 x 35 Washer Ø 12 Locked Nut Shock Absorber 50 x 60 Lock Washer Ø 12 Bottom Plate 540 x 450 v.211220 | 33...
Page 34
Lock Washer Ø8 Washer 8 x 24 Belt Cover 240 x 190 Engine Support Plate 490 x 425 External Hexagon Bolt M8 x 40 Exciter 04-01 Washer Ø16 Lock Washer Ø16 Inner Hexagon Bolt M16 x 40 34 | OPV425 man.
Page 35
PARTS & SCHEMATICS ENGINE FRAME Description Qty. Specification Engine Frame Metal Washer 10 mm Lock Washer 10 mm External Hexagon Bolt M10 x 30 v.211220 | 35...
Page 36
Ø14 Oil Drainage Bolt M14 x 1.5 Case Cover (Pulley) 04-02 Oil Seal 35 x 52 x 7 Pulley 04-06 Lock Washer 10 x 35 Large Washer 10 x 35 Inner Hexagon Bolt M10 x 25 36 | OPV425 man.
Page 37
PARTS & SCHEMATICS CLUTCH AND BELT Description Qty. Specification Engine CH270 5 x 40 Clutch Assembly 128 x 20 Conical Washer 8 x 30 x 6 Lock Washer Ø8 External Hexagon Bolt M8 x 30 Locked Nut Washer Ø8 Belt A-737 External Hexagon Bolt M8 x 45...
Page 38
410 x 365 Throttle Line Assembly 0.9m Locked Nut Flange Bolt M10 x 35 Locked Nut Scan here to access the DK2 POWER Parts Store or open your browser and go to www.detailk2.com/shop-power-equipment-parts Your Compactor model is: OPV425 38 | OPV425 man.
Page 39
If within one (1) year from the original date of purchase this product fails due to defect in material or workmanship, Detail K2 will repair, replace, or supply any covered defective part at our option. DK2 POWER is 1-year parts only warranty no labor. Kohler 3 year warranty is PARTS and LABOR.
