– BU: Blau
– GN/YE: Gelb und grün
– BK: Schwarz
– GY: Grau
Je nach Anschlussart bei Bedarf die vom Werk
7.
gelieferten Aderendhülsen anders anordnen.
Um bei Bedarf zwei Kabel zu verbinden, eine Ade-
8.
rendhülse einsetzen.
Die Adern kürzen.
Die Isolierung entfernen.
Funktion prüfen
Das Gerät einschalten.
1.
Wenn
,
oder
2.
nicht richtig angeschlossen. → "Elektrischen An-
schluss prüfen und korrigieren", Seite 19
Wenn kein Fehler in der Anzeige des Geräts er-
3.
scheint, die Funktion der Lüftung anhand der Ge-
brauchsanleitung prüfen.
Elektrischen Anschluss prüfen und korrigieren
Das Gerät vom Stromanschluss trennen.
1.
Prüfen, ob der Anschluss am Gerät und der ge-
2.
bäudeseitige Anschluss dem Anschlussschema in
dieser Montageanleitung entsprechen. → "Elektri-
schen Anschluss vorbereiten", Seite 16 → "Strom-
anschluss herstellen", Seite 18
Bei 3 N die folgende Abbildung beachten.
3.
→ Abb.
49
Bei 2 N die folgende Abbildung beachten.
4.
→ Abb.
50
Bei 1 N die folgende Abbildung beachten.
5.
→ Abb.
51
Anzeige auf Abluftbetrieb umstellen
Bei Bedarf für den Abluftbetrieb die Anzeige der
1.
elektronischen Steuerung in den Grundein-
stellungen umstellen.
Das Kapitel Grundeinstellungen in der Gebrauchs-
2.
anleitung beachten.
Gerät ausbauen
ACHTUNG!
Werkzeuge können den Geräterahmen beschädigen.
Das Gerät nicht von oben heraushebeln.
Das Gerät vom Stromnetz trennen.
1.
Den Abluftkanal entfernen oder die Umluftverbin-
2.
dungen lösen.
Das Gerät von unten herausdrücken.
3.
en
Scope of delivery
After unpacking all parts, check for any damage in
transit and completeness of the delivery.
→ Fig.
1
QR code for the installation video
This is were you will find the QR code for the installa-
tion video.
→ Fig.
2
Appliance dimensions
You will find the dimensions of the appliance here
→ Fig.
3
leuchtet, ist das Gerät
Installation dimensions for flat duct bends
This is where you can find an overview of the install-
ation dimensions for the flat duct bends.
Side view:
→ Fig.
, → Fig.
, → Fig.
4
5
Front view:
→ Fig.
7
Installation variants
This is where you can find an overview of the differ-
ent installation variants.
Odour filter and adapter for circulating-air mode:
→ Fig.
8
Acoustics filter and seal for air extraction mode:
→ Fig.
9
Note: Channels suitable for installation can be ob-
tained from customer service, our website or from
specialist retailers.
Safety clearances
Comply with the safety clearances for the appliance.
Clearances to the overflow container:
→ Fig.
10
Position of the overflow container:
→ Fig.
11
The performance is optimal at a clearance of 50 mm
between the unit back panel and the wall. The per-
formance is reduced at a smaller clearance.
→ Fig.
12
Observe the safety clearances for the worktop cut-
out.
Do not place any objects in the drawer which exceed
the maximum height of the drawer. The objects may
come into contact with the base of the appliance
and thus disrupt the functions.
→ Fig.
13
General information
¡ Read this instruction manual carefully.
¡ Only a licensed expert may connect the
appliance.
¡ Switch off the power supply before carry-
ing out any work.
¡ Never use this appliance in boats or in
vehicles.
¡ Follow the worktop manufacturer's recom-
mendations.
Safe installation
Follow these safety instructions when installing the
appliance.
The appliance can only be used safely if it is cor-
rectly installed according to the safety instructions.
The installer is responsible for ensuring that the ap-
pliance works perfectly at its installation location.
Note: This appliance is designed to capture steam
from cookware on the cooking zone. If the vapours
are captured by other appliances (such as universal
kitchen machines or hobs), the efficiency of the vent-
ilation system depends on the distance between the
air inlet and the source of the vapours.
WARNING ‒ Danger: Magnetism!
The appliance contains permanent magnets. They
may affect electronic implants, e.g. pacemakers or
insulin pumps.
Persons with electronic implants must stand at
least 10 cm away from the appliance.
6
19
