Inserting a tool
WARNING! Risk of injury! Make sure
that when installing the tool that it fits
securely in the clamping chuck and is not
at an angle.
Note: Clean and grease the shaft of the
tool before inserting.
► P. 3, fig. 2
– Pull the tool holder (1) back.
– Insert the required tool with a slight turn until the
tool holder locks.
Selecting the operating mode
NOTICE! Risk of damage to the unit!
Only change operating mode when the
device is switched off.
NOTICE! Risk of damage to the unit!
Do not use settings [
for screwing in and removing screws. Do
not use settings [
ing.
Note: The position [
rotate the tool to the required position. To
chase, the switch (7) must be set to posi-
tion [
].
– Press the lock button (8) and set the switch (7) to
the required operating mode:
• Position [
] for drilling without the hammer
function into wood, metal, ceramics and plastics
and for the screwdriver function.
• Position [
] for hammer drilling in cement or
stone.
• Position [
] for chasing in cement or stone.
Changing the rotation direction
NOTICE! Risk of damage to the unit!
Only use the rotation direction switch
when the device is at a standstill.
– To drill and screw screws into place, press the
rotation direction switch (6) to the left (rotation in
clockwise direction).
– To remove screws, press the rotation direction
switch to the right (rotation in an anti-clockwise
direction).
Check before switching on!
Check to make sure the unit is in a safe operating
condition:
Error/Fault
Tool holder does not turn.
Chuck is turning, but the device
is not drilling.
No hammer drilling function.
No chasing function.
If you can't fix the fault yourself, contact your nearest
vendor. Please be aware that any improper repairs
will also invalidate the warranty and additional costs
], [
] and [
]
] and [
] for chas-
] is only used to
Cause
No power supply?
Is the device defective?
Revolution direction set incorrect-
ly?
Mode switch is not set correctly? ► Selecting the operating mode – p. 23
– Check to make sure there are no visible defects.
– Check to make sure all unit components are cor-
rectly mounted.
Switching on and off
– Switching on: Press down the On/Off switch (5).
– To operate permanently, press the locking but-
ton (4) whilst holding down the the On/Off switch.
– Press the On/Off switch again and release to
release the lock.
– Switching off: Release the On/Off switch (5)
again.
Drilling
DANGER! Risk of injury! Never hold the
work piece that you are working with in
your hand, on your lap, or against other
body parts.
NOTICE! Risk of damage to the unit!
Never use the drill for chasing or to
expand drilled holes.
Always use a drill appropriate to the mate-
rial.
– Hold the device straight and drill with even pres-
sure.
Cleaning and maintenance
Cleaning overview
Regularly and according to the operating condi-
tions
What?
Clean the ventilation slots
of the motor to remove
dust.
Clean the device.
Troubleshooting
What to do when something doesn't work...
DANGER! Exercise caution – risk of
injury! Unprofessional repairs may mean
that your unit will no longer operate safely.
This endangers you and your environ-
ment.
Malfunctions are often caused by minor faults. You
can easily remedy most of these yourself. Please
consult the following table before contacting the ven-
dor. You will save yourself a lot of trouble and possibly
money too.
Remedy
Check the cable, plug, and the fuse.
Contact your local vendor.
Switch the rotation direction reversing
switch
may be incurred.
GB
How?
Use a vacuum, cleaning
brush or paint brush.
Wipe the unit with a damp
cloth.
23
