4.2 Introduction to the panel
7
9
6
NUM. Name
1 Input voltage
2 Temperature display
3 Adjustment wheel
4 HF/LIFT selection
5 2T/4T selection
6 PULSE selection
7 Waveform selection
Welding mode
8
selection
9-1 PRE-GAS (s)
9-2 I (A)
S
9-3 T (s)
UP
9-4 I1 (A)
Notices_multilangues_200ACDC.indd 25 Notices_multilangues_200ACDC.indd 25
8
5 4
Mode Effect
Indicates that the device is connected to a power source.
Indicates that the machine is protected against overheating.
Press to confirm and select another setting
Turn to adjust value
HF - high-frequency starting arc
TIG
LIFT - touch start arc
2T - 2-stroke mode
TIG
4T - 4-stroke mode
PULSE OFF
TIG
PULSE ON
Sine wave
TIG AC Triangular wave
Square wave
TIG AC: AC TIG mode for aluminium
TIG DC: TIG direct current mode for all metals except aluminium
TIG SPOT: TIG mode for aiming
MMA: coated electrode welding mode
TIG Gas diffusion time before arc ignition
TIG AC or DC Starting arc current
TIG SPOT Spot welding arc current
TIG AC or DC Time needed to go from Is to I1
TIG AC or DC Welding current
1
2
3
25
