1.
The machine is fitted with two ergono-
mically designed levers. The operator
MUST hold the rounded tip lever (7) and
the carriage assembly motion control
lever (8) when cutting keys.
9. Tracer depth adjustment handle: This is used to adjust the
coding depth, with centesimal precision.
10. Brush: Used to remove any possible burr from the key
after the cutting process.
11. Power switch:
1.
If the switch is lit, it means the machi-
ne is running.
12. Protective shield: Provides protection from the cutter and
the belt.
13. Handle: For making it easier to carry the machine.
14. Jack connector: Connect to the power adapter when
needing to charge the battery.
15. Master switch: this switch needs to be ON to operate the
machine.
16. Safety switch protective screen: To prevent accidental use
of the master switch.
17. Battery: for being able to use the machine without nee-
ding a mains connection.
18. Battery charge indicator: Pressing the red circle will dis-
play the battery charge level.
4.4 TECHNICAL DATA
The main technical data is shown below:
Power supply: 29.4 V - 1A
Battery: Ion-lithium 25.9 V 2500 mAh
Motor: 24 VDC - 150 W
Cutter: High-speed steel (HSS); Ø63 x 1.4 mm (three cuts),
with a Ø16 orifice
Cutter speed: 2,100 rpm
Clamps: Three-way steel clamps.
Carriage movement: On bearings.
Carriage range (maximum rail length): 73 mm
Dimensions: Width = 266 mm; depth = 260 mm; height =
165 mm
Weight: 9 kg
KEY CUTTING MACHINE
MÁQUINA DUPLICADORA
4.5 COMPONENTS AND FUNCTIONAL PARTS
4.5.1 Accessories
1. Machine anchoring tool.
2. Adjustment rods.
3. Rod for changing the cutter or brush.
4. Set of Allen keys (2, 3, 4 and 5 mm).
5. Battery charger.
See Figure 3
4.5.2 Wiring diagram
The main components of the electrical and electronic circuit
are the following:
1. Jack connector
2. Battery
3. Driver
4. Motor
5. Master switch
6. On/off switch
7. Battery charge indicator
See Figure 4
4.5.3 Battery
The machine has a screen with a battery charge indicator.
To display the charge level at any given time, just press the
red TEST circle. A series of blue diodes will illuminate to show
the charge percentage (25%, 50%, 75% or 100%). If only the
first red diode illuminates, that means that the battery is flat
and it needs to be charged to 100% again.
NOTE: When the battery charge level falls very low, the
cutter will suddenly stop rotating. This does not mean that
the machine is faulty but rather that the battery needs to be
recharged.
TEST
TEST
25%
25%
50%
50%
75%
75%
100%
100%
