Safety
TPS 2700 Duo The TPS 2700 Duo TIG power source is a combination of the TPS 2700 Duo power
TIG source and the TPS 2700 TIG source.
For any information that is additionally required for the TPS 2700 Duo TIG power source
please refer to the User Manual TPS 2700 TIG.
"FK 4000 R Duo" The "FK 4000 R Duo" conversion kit (4,100,390) allows connecting additional water
conversion kit lines for an external wire feeder. It is possible to connect one water-cooled welding
torch to the power source and one water-cooled welding torch to an external wire feeder
at the same time.
Important! The FK 4000 R US cooling unit includes the optional "FK 4000 R flow
controller" already as a standard.
If possible, mount the "FK 4000 R Duo" conversion kit before the installation of the
cooling unit. Fig.2 shows the simultaneous coolant flow through two welding torches.
Fig.2
Warning! Maloperation can cause severe damage to persons and material
damage. Before the first start-up thoroughly read the following chapters of the
User Manual TS 4000/5000 and TPS 2700/4000/5000:
- safety instructions
- before the start-up
- starting operation of the power sources
Note! In connection with the TPS 2700 Duo / TPS 2700 Duo TIG power source
only use the FK 4000 R cooling unit with the optional "FK 4000 R flow control-
ler" (4,100,214).
Coolant flow through two welding torches connected at the same time
2
welding torch 1
welding torch 2
