TECHNICAL DATA
Parameter description
Parameter value
Product name
Beer dispenser
Model
RCBD-5L
RCBD-5LB
Rated voltage [V~]/
230/50
Frequency [Hz]
Rated power [W]
65
Keg volume [l]
5
Cooling temperature [°C]
2-12
Dimensions [mm]
495x270
480x272
x485
x480
Weight [kg]
6,5
5,5
1. GENERAL DESCRIPTION
The user manual is designed to assist in the safe and
trouble-free use of the device. The product is designed
and manufactured in accordance with strict technical
guidelines,
using
state-of-the-art
technologies
components. Additionally, it is produced in compliance
with the most stringent quality standards.
DO NOT USE THE DEVICE UNLESS YOU HAVE
THOROUGHLY READ AND UNDERSTOOD THIS
USER MANUAL.
To increase the product life of the device and to ensure
trouble-free operation, use it in accordance with this user
manual and regularly perform maintenance tasks. The
technical data and specifications in this user manual are
up to date. The manufacturer reserves the right to make
changes associated with quality improvement. The device
is designed to reduce noise emission risks to a minimum,
taking into account technological progress and noise
reduction opportunities.
LEGEND
The product satisfies the relevant safety
standards.
Read instructions before use.
The product must be recycled.
WARNING! or CAUTION! or REMEMBER!
Applicable to the given situation (general
warning sign).
ATTENTION! Electric shock warning!
ATTENTION! Fire hazard - flammable materials!
Class II protection device with double insulation.
PLEASE NOTE! Drawings in this manual are for
illustration purposes only and in some details may
differ from the actual product.
The original operation manual is written in German. Other
language versions are translations from the German.
8
U S E R M A N U A L
2. USAGE SAFETY
ATTENTION! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury or even death.
The terms „device" or „product" are used in the warnings
and instructions to refer to <Beer dispenser>. Prevent the
device from getting wet. Risk of electric shock! Do not
cover the ventilation openings!
2.1. ELECTRICAL SAFETY
a)
The plug must fit the socket. Do not modify the
plug in any way. Using original plugs and matching
sockets reduces the risk of electric shock.
b)
Do not touch the device with wet or damp hands.
c)
Use the cable only for its designated use. Never
use it to carry the device or to pull the plug out of
a socket. Keep the cable away from heat sources, oil,
sharp edges or moving parts. Damaged or tangled
cables increase the risk of electric shock.
d)
If using the device in a damp environment cannot
be avoided, a residual current device (RCD) should
be applied. The use of an RCD reduces the risk of
electric shock.
and
2.2. SAFETY IN THE WORKPLACE
a)
Do not use the device in a potentially explosive
environment, for example in the presence of
flammable liquids, gases or dust. The device
generates sparks which may ignite dust or fumes.
b)
If you discover damage or irregular operation,
immediately switch the device off and report it to
a supervisor without delay.
c)
If there are any doubts as to the correct operation of
the device, contact the manufacturer's support service.
d)
Only the manufacturer's service point may repair the
device. Do not attempt any repairs independently!
e)
In case of fire, use a powder or carbon dioxide
(CO
) fire extinguisher (one intended for use on live
2
electrical devices) to put it out.
f)
Regularly inspect the condition of the safety labels. If
the labels are illegible, they must be replaced.
g)
Please keep this manual available for future
reference. If this device is passed on to a third party,
the manual must be passed on with it.
REMEMBER! When using the device, protect children
and other bystanders.
2.3. PERSONAL SAFETY
a)
Do not use the device when tired, ill or under the
influence of alcohol, narcotics or medication which can
significantly impair the ability to operate the device.
b)
The device is not designed to be handled by persons
(including children) with limited mental and sensory
functions or persons lacking relevant experience
and/or knowledge unless they are supervised by
a person responsible for their safety or they have
received instruction on how to operate the device.
c)
To prevent the device from accidentally switching on,
make sure the switch is on the OFF position before
connecting to a power source.
d)
The device is not a toy. Children must be supervised
to ensure that they do not play with the device.
2.4. SAFE DEVICE USE
a)
Do not use the device if the ON/OFF switch does not
function properly (does not switch the device on and
off). Devices which cannot be switched on and off
using the ON/OFF switch are hazardous, should not
be operated and must be repaired.
Rev. 19.03.2019
b)
Disconnect the device from the power supply
before commencement of adjustment, cleaning and
maintenance. Such a preventive measure reduces
the risk of accidental activation.
c)
When not in use, store in a safe place, away from
children and people not familiar with the device who
have not read the user manual. The device may pose
a hazard in the hands of inexperienced users.
d)
Keep the device in perfect technical condition.
Before each use check for general damage and
especially check for cracked parts or elements and
for any other conditions which may impact the safe
operation of the device. If damage is discovered,
hand over the device for repair before use.
e)
Keep the device out of the reach of children.
f)
Device repair or maintenance should be carried out
by qualified persons, only using original spare parts.
This will ensure safe use.
g)
To ensure the operational integrity of the device, do
not remove factory-fitted guards and do not loosen
any screws.
h)
Clean the device regularly to prevent stubborn grime
from accumulating.
i)
The device is not a toy. Cleaning and maintenance
may not be carried out by children without
supervision by an adult person.
j)
Never remove the keg from the device before the
keg is empty.
k)
Never remove the CO
cartridge from the device
2
before the cartridge is used up.
l)
Never use CO
cartridges in rooms where the
2
temperature exceeds 49°C. This creates a risk of
explosion.
m)
Do not cover the device or put other objects on it.
n)
Opening the top lid for long periods can cause
a significant increase of the temperature in the
compartments of the appliance.
o)
Regularly clean surfaces that can come into contact
with food and accessible drainage systems
ATTENTION! Despite the safe design of the device
and its protective features, and despite the use of
additional elements protecting the operator, there is
still a slight risk of accident or injury when using the
device. Stay alert and use common sense when using
the device.
3. USE GUIDELINES
The beer dispenser is designed for cooling and pouring
beer from keg type barrels. Do not use the beer dispenser
for cooling other liquids and drinks in cans, bottles, etc.
The user is liable for any damage resulting from
unintended use of the device.
3.1. DEVICE DESCRIPTION
RCBD-5LB
1
9
12
2
3
6
10
4
7
11
5
8
Rev. 19.03.2019
RCBD-5L
1
13
15
2
10
9
3
6
14
7
4
5
8
1.
top lid
2.
pouring handle
3.
Dispenser
4.
release button
5.
drip tray
6.
Rear cover
7.
power cable
8.
ON/OFF switch
9.
top lid opening button
10.
LED temperature display
11.
Temperature adjustment button
12.
CO
cartridge shield with pin
2
13.
CO
cartridge
2
14.
Filter
15.
CO
pressure adjustment knob
2
3.2. PREPARING FOR USE
APPLIANCE LOCATION
The temperature of environment must not be higher than
40°C and the relative humidity should be less than 85%.
Ensure good ventilation in the room in which the device
is being used. There should be at least 10 cm distance
between each side of the device and the wall or other
objects. Keep the device away from hot surfaces. Operate
the device on an even, stable, clean, fire-proof and dry
surface and out of the reach of children and persons with
mental disabilities. Position the device such that you always
have access to the power plug. The power cord connected
to the appliance must be properly grounded and
correspond to the technical details on the product label.
ASSEMBLING THE DEVICE
ATTENTION! Before attaching a beer barrel, pour approx.
800 ml of clean, cool water into the device. This will help
cool the beer down quicker.
Avoid pouring in excessive amount of water to avoid leaks
after the keg is installed. It may damage the device.
ATTENTION! Before attaching a barrel, read and follow
instructions shown on every beer barrel in order to
eliminate unnecessary gas leaks and prevent foam leaking
from the tap.
ATTENTION! Please read the instructions for removing the
seal protecting the keg, provided by the manufacturer.
9
