Gima K10 Manuel D'utilisation page 25

Gender PID Patient type
Patient information area (as shown in the figure above): the patient whose information displayed
⚫
on the Message indication area is monitored by device currently. Icon "
female, " " is male and "
When the user does not fill any patient information, the device uses the default patient
information. The default patient ID is "00000000", Name is "Noname", the patient type is "Adult".
Move the cursor on this information area can shift to "Patient Info." setting window.
Physiological alarm sources (as shown in the figure above): displays physiological alarm source
⚫
information.
Alarm status: See Chapter 6 Alarms.
⚫
Extended module info: when the extension modules are identified, the corresponding module
⚫
icons will appear on the upper right screen, "
" for CSM module.
Note

If you purchased the monitor with extended module, then the corresponding module icon(s)
will also appear on the upper right screen.
2.3.2 Statusbar
From left to right of the status bar, it shows "Menu", "Alarm", and "Review" button, technical alarm event,
printer status, pulse beep status, power supply status, current time.
"Menu" button "Alarm" button "Review" button
"Menu" button enters into system menu dialog.
⚫
"Alarm" button: enters into alarm setting dialog.
⚫
"Review" button enters into the data review dialog.
⚫
Technical alarm event: displays the current detected a technical alarm event and detailed
⚫
technical alarm information. Refer to the Chapter 6 Alarm for details.
Icons of printer status (optional): there are 3 printer status as below:
⚫
➢
: it means the printer is ready.
Patient name
" is unknown. The device presets default patient information.
" for CO
Technical alarm event
13
Physiological alarm information
module,
2
Printer Beep volume
Alarm status
Extended module info
" means the patient is
for IBP module, and "
Power supply
System time
