Installation and Operating Specification EDR
8 Enclosure
8.1 Technical data
Type
Part-No.
mains
Max. load output 0...10 V
(short-circuit-proof)
Max. current consumption ca.
Pressure connections "+, -"
Housing
Use position
Protection rating
Weight
Permissible ambient temperature
Permissible medium temperature
Permissible temperature range for
storage and transport
Permissible rel. humidity
One-sided permissible overload
Burst prssure
Maximum cross section of terminals
Interference emission
Interference immunity
L-BAL-E292-GB 2023/51 Index 002
EDR
01437
10...24 V DC (+20 %)
Protected against reverse polarity
@ U 10 V DC
S
0.3 mA
6 mA
Hose connectors d = 5 / 6 mm
PC (polycarbonate)
Fire protection classification UL94V0
vertical (measuring depends on position)
IP54 according EN 60529
approx. 230 g
(0.50 lb)
-10...60 °C
(14...140 °F)
-10...70 °C
(14...158 °F)
-30...70 °C
(-22...158 °F)
85 % no condensation
0.1 bar
(80 in.wg)
at room temperature: 0.2 bar
at 70 °C (158 °F): 0.15 bar
2
1.5 mm / AWG16
Interference emission EN IEC 61000-6-3 (do-
mestic household applications)
Interference immunity EN IEC 61000-6-2 (in-
dustrial applications)
Part.-No.
17/21
Enclosure
@ U 13...24 V DC
S
10 mA
14 mA
(0.20 / 0.24 inch)
(80 in.wg)
(60 in.wg)
