Cleaning the equipment

To clean, take the variable parts out of the appliance.
"Interior fittings" on page 29
~
Partition and vegetable container cover
Taking out the partition
▯
Remove glass plate, press levers on the underside
on both sides, pull partition forwards, lift and swivel
out to the side.
1
Taking out the vegetable container cover
▯
Lift cover, pull forwards and swivel out to the side.
Inserting vegetable container cover and partition
1 Insert vegetable container cover.
2 Insert partition.
3 Insert glass plate.
4
2
3
Telescopic rails
Removing telescopic rails
1 Pull out telescopic rail.
2 Push lock in the direction of the arrow.
3 Detach telescopic rail from the rear pin.
4 Push telescopic rail together, push backwards
above the rear pin and disengage.
Installing telescopic rails
1 Place the extended telescopic rail on the front pin.
2 Pull the telescopic rail forwards slightly until it
engages.
3 Insert telescopic rail on the rear pin.
4 Push lock backwards.
Cleaning
