Introduction; Specifications; General Specifications - Baxtran XTA Manuel D'utilisation

2. INTRODUCTION

XTA & XTA-P scales are very compact, reliable, high accuracy and much stable.
It uses 15mm LCD display with LED backlight, with the different back light operation,
Weighing unit conversion /kg and /100g and change function.
20 membrane keyboard
10 indirect PLU, it can store 10 unit price values
Auto unit price clear operation (SAVE function)

3. SPECIFICATIONS

3.1. GENERAL SPECIFICATIONS

MODEL
Display
Gross weight
Capacity
Readability
Max. Divisions
Weighing Units
Pan size
Housing
Operation Temperature
Stability Time
Power
Keypad
Zero range
Signal input range
ADC
Internal counts
ADC update
Load cell drive voltage
6
XTA / XTA-P
15mm LCD Display with white LED back Light
4.1kg (XTA) / 4,5kg (XTA-P)
3/6kg 6/15kg
1/2g 2/5g
2 x 3000e
kg
204 x 263 mm
ABS plastic and stainless steel pan
-10°C ~ +40°C
1 seconds typical
AC switching adaptor 12V/2500mA.
Rechargeable battery 6V/3.2Ah
20 keys
0mV~5mV
0~15mV
Sigma delta
600,000
Max. 60 times/second
Max. 5V/150mA
USER MANUAL XTA
15/30kg
5/10g
EN
