Operating Parts And Connections - Festo DNCI-32 Notice D'utilisation

DNCI
Standard cylinder
1

Operating parts and connections

9
8
7
6 5
1
Compressed air connections
2
Grooves for proximity switch
3
Electrical connection of the measuring
head
4
Measuring head
5
Flange screws with threaded holes for
fastening
Fig. 1
Festo DNCI 0810b English
DNCIEnglish
4
6
Piston rod with integrated magnetic
measuring tape
7
Pivot for counter holding the piston rod
8
Centering collar
9
Earth/ground connection
1
2
3
