ENGLISH
• Current humidity display (detected by the humidity
sensor) (fig.9b);
9c 9c
Residual operating time at Vmax, (fig.9c)
depending on preset Timer duration (see TIMER
button)
9c 9c
Other information displayed automatically, depending
on the conditions:
• Value set during initial configuration of V min , V max
(only during the installer set up stage)
• Clockface symbol: if the Timer function is set (see
"TIMER button")
• Battery charge low (see "Warning/error signals")
• System malfunction (see "Warning/error signals")
22
O
17
O
17
TIMER Button (fig.10)
10 10
14:38
DISPLAY
SET
It forces the device to operate at Max Speed for 10
min (press key for 0.5 sec), 20 min (press twice), 30
min (press three times), or continuosly (press four
times). Pressing the key for a fifth time (OFF) restores
operation at the previously set speed, unless over-
ridden by the sensors.
The display will also show (fig.10a):
10a 10a
• the TIMER icon;
• the MODE icon;
• the duration set (10,20,30,CO);
• the Max Speed icon.
Once the scheduled time has elapsed or if you press
the TIMER button 5 times until OFF appears, the
appliance will go back to working at minimum speed
(except commands from the RH sensor) and the
display will no longer show the clock symbol.
AUTO
Fr
TIMER
MODE
NEXT ENTER
O
20
AUTO
