HOPPER LIFTING SYSTEM HYDRAULIC DIAGRAM

Key
1. Oil tank
2. Oil fi lter
3. Pump
4. Motor
5. Lifting cylinder safety valve
6. Hopper lifting cylinder
1

DRIVE SYSTEM HYDRAULIC DIAGRAM

Key
1. Oil tank
2. Oil fi lter
3. Pump
4. Motors
6
5
200 BAR
110 BAR
750cc / HYDRAULIC OIL 32 cSt
SR 1300H P
200 BAR
3
70 BAR
4
2
A
C
B
146 1064 000(3)2007-02 A
USER MANUAL
B
ENGLISH
S310132
S310191
13
