Working Advice

 Exercise caution when cutting slots in structural walls;
see Section "Information on Structures".
 Clamp the workpiece if it does not remain stationary
due to its own weight.
 Do not strain the machine so heavily that it comes to a
standstill.
 After heavily straining the power tool, continue to run
it at no-load for several minutes to cool down the acces-
sory.
 Do not touch grinding and cutting discs before they
have cooled down. The discs can become very hot while
working.
 Do not use the power tool with a cut-off stand.
Rough Grinding
 Never use a cutting disc for roughing.
The best roughing results are achieved when setting the ma-
chine at an angle of 30° to 40°. Move the machine back and
forth with moderate pressure. In this manner, the workpiece
will not become too hot, does not discolour and no grooves
are formed.
Flap Disc
With the flap disc (accessory), curved surfaces and profiles
can be worked.
Flap discs have a considerably higher service life, lower noise
levels and lower sanding temperatures than conventional
sanding sheets.
Cutting Metal
 For cutting with bonded abrasives, always use the pro-
tection guard for cutting 12.
When cutting, work with moderate feed, adapted to the mate-
rial being cut. Do not exert pressure onto the cutting disc, tilt
or oscillate the machine.
Do not reduce the speed of running down cutting discs by
applying sideward pressure.
Bosch Power Tools
Cutting hard materials
 Wear a suitable dust mask, e.g. P2 Standard.
 The machine may be used only for dry cutting/grinding.
For cutting especially hard material, e.g., concrete with high
pebble content, the diamond cutting disc can overheat and
become damaged as a result. This is clearly indicated by cir-
cular sparking, rotating with the diamond cutting disc.
In this case, interrupt the cutting process and allow the dia-
mond cutting disc to cool by running the machine for a short
time at maximum speed with no load.
Noticeably decreasing work progress and circular sparking
are indications of a diamond cutting disc that has become
dull. Briefly cutting into abrasive material (e.g. lime-sand
brick) can resharpen the disc again.
Information on Structures
Slots in structural walls are subject to the Standard DIN 1053
Part 1, or country-specific regulations.
These regulations are to be observed under all circumstanc-
es. Before beginning work, consult the responsible structural
engineer, architect or the construction supervisor.
Recommendations for Optimal Handling of the Battery
Protect the battery against moisture and water.
Store the battery only within a temperature range between
–20 °C and 50 °C. As an example, do not leave the battery in
the car in summer.
Occasionally clean the venting slots of the battery using a soft,
clean and dry brush.
A significantly reduced working period after charging indi-
cates that the battery is used and must be replaced.
Observe the notes for disposal.

Maintenance and Service

Maintenance and Cleaning

 Before any work on the machine itself (e.g. mainte-
nance, tool change, etc.) as well as during transport
The machine must
and storage, remove the battery from the power tool.
always work in an up-
There is danger of injury when unintentionally actuating
grinding motion. Other-
the On/Off switch.
wise, the danger exists
 For safe and proper working, always keep the machine
of it being pushed
and ventilation slots clean.
uncontrolled out of the
 Please store and handle the accessory(-ies) carefully.
cut.

After-sales Service and Application Service

When cutting profiles
and square bar, it is best
Our after-sales service responds to your questions concern-
to start at the smallest
ing maintenance and repair of your product as well as spare
cross section.
parts. Exploded views and information on spare parts can
also be found under:
www.bosch-pt.com
Bosch's application service team will gladly answer questions
concerning our products and their accessories.
In all correspondence and spare parts orders, please always
include the 10-digit article number given on the nameplate of
the product.
