SilverCrest SAS 7.4 LI C2 Mode D'emploi page 25

2) Select a suitable installation location for the wall bracket 3:
It must be possible to remove the handheld vacuum cleaner easily and there
must be an accessible mains power socket for the mains adapter 4 .
3) Drill two holes about 34 mm apart . Use the wall bracket 3 to mark the holes,
to ensure the correct spacing . The drill holes must be suitable for 6 mm wall
plugs .
4) Push the wall plugs into the holes and then screw the wall bracket 3 firmly
into place using the screws .
5) You can place the nozzles on the accessories holder on the side .
6) Connect the mains adapter 4 to a mains power socket .
Charging
NOTE
► Ensure that the on/off switch 6 has been pushed back (and thus the appli-
ance is switched off) before starting the charging process .
■ Place the handheld vacuum cleaner from above into the wall bracket 3 so
that the barrel plug 5 slips into the socket on the handheld vacuum cleaner .
The charge indicator lamp 7 lights up red and the charging process begins .
■ When charging is complete, which can take around 5 hours with fully dis-
charged batteries, the appliance automatically switches to a trickle charge
(maintenance function) . The charge indicator lamp 7 lights up green .
Nevertheless, in order to avoid possible damage to the batteries, do not
leave the appliance permanently connected to the mains adapter 4 .
■ Do not recharge the batteries again until the handheld vacuum cleaner's
suction power becomes appreciably weaker and the charge indicator lamp 7
flashes green .
NOTE
► If the handheld vacuum cleaner is deep-discharged, the charge indicator
lamp 7 flashes alternately red and green (approx . 1 minute) . In this case,
switch off the appliance and start charging .
► The handheld vacuum cleaner can also be charged directly via the mains
adapter 4 . To do this, remove the barrel plug 5 with a slight twist from
the wall bracket 3 and insert it into the socket on the handheld vacuum
cleaner .
■ 22 │ GB │ IE SAS 7.4 LI C2
