2.3. Operation of the LEDs

Mode
Product in Park mode
Magnet detection process (1 to 6 seconds)
FR
Product start (after detection of the magnet) OFF
Joining process (Lora product)
EN
Detection of the good communication
between the product Modbus and slaves
Switching to the Command mode
Product faulty (return to factory)
LED red state
OFF
OFF
During the JOIN phase: flashing: 50ms on / 1
s off
If the JOIN phase is complete (JOIN accept):
flashing: 50ms on / 50ms Off (6x)
10 seconds ON if a default is detected
Continuously lit
Fixed ON
LED green state
OFF
ON from detection of the magnet up to a
maximum of 1 second
Rapid flashing 6 cycles, 100 ms ON / 100
ms OFF
During the JOIN phase: flashing: 50ms on /
1 s off (just after the red LED)
If JOIN phase is complete (JOIN accept):
flashing: 50ms on / 50ms off (just before the
red LED)
10 seconds ON if no default detected
Continuously lit
