Replacement Parts Diagram - AirKing AKLC701 Manuel D'utilisation

2
15
16
# Qty. Description
1 1 Fan Housing
2 4 Mounting Rails
3 1 Collar/Damper
4 1 External Wire Cover
5 1 Gasket - Collar
6 1 Interior Wire Cover
7 1 #8 B Screw
8 2 #6 B Screw
9 1 Polarized Connector
10 1 Receptacle
11 1 Motor
12 3 Motor Mounting Screw
13 1 Blower Wheel
14 1 Cap Screw
15 1 Blower Housing
210572200 Rev. A 6-06

REPLACEMENT PARTS DIAGRAM

4
1
6
14
13
Replacement Part #
5S1234001
5S1299002
5S1299006
5S2299014
5S2299015
5S2234001
5S1299007
5S1999010
5S1299008
5S1999001
5S2234002
5S2234003
5S2234004
5S2234005
5S2234006
8
7
5
9
10
11
12
24
# Qty. Description
16 1
17 1
18 1
19 1
1
1
1
20 2
21 1
22 1
23 1
1
1
1
24 1
www.airkinglimited.com
3
17
18
19
21
23
#10 B Screw
Nut
Lockwasher
Base - Bronze
Base - Nickel
Base - White
Base - Brass
Mounting Screws
Mounting Rod
Glass
Knob - Bronze
Knob - Nickel
Knob - White
Knob - Brass
Lamp Holder
20
22
Replacement Part #
5S1299009
5S5204008
5S5204007
5S5204106
5S5204206
5S5204306
5S5204906
5S5204004
5S5204005
5S5204003
5S5204101
5S5204201
5S5204301
5S5204901
5S5204002
6 of 12
