Fm / Csa - ABB TZIDC Mode D'emploi

Positionneur électro-pneumatique TZIDC
pour technique à deux fils 4 ... 20 mA
6.3

FM / CSA

6.3.1 CSA International
Certificate:
Class 2258 02
Class 2258 04
Class I, Div 2, Groups A, B, C and D;
Class II, Div 2, Groups E, F, and G,
Class III, Enclosure Type 4X:
Model TZIDC, P/N V18345-x0x2x2xx0x Intelligent Positioner
Input rated
Max output pressure
Max. ambient
Class I, Div 1, Groups A, B, C and D;
Class II, Div 1, Groups E, F and G
Class III, Enclosure Type 4X:
Model TZIDC, P/N V18345-x0x2x2xx0x Intelligent Positioner
intrinsically safe with entity parameters of:
Terminals 11 / 12
Terminals 81 / 82
Terminals 83 / 84
Terminals 31 / 32
Terminals 41 / 42 and 51 / 52
Terminals Limit2 41 / 42 and
Limit1 51 / 52
When installed per installation Drawing No 901064
Temperature Code
Max. Ambient
IMPORTANT (NOTE)
• The "x" in P/N denotes minor mechanical variations or
optional features.
• Local communication interface LKS shall not be used in
hazardous location.
• Each pair of conductors of each intrinsic safety circuit
shall be shielded..
1052414
PROCESS CONTROL
EQUIPMENT –
For Hazardous Locations
PROCESS CONTROL
EQUIPMENT – Intrinsically
Safe, Entity – For Hazardous
Locations
30 V DC; max. 4 ... 20 mA
90 psi
85 Deg C
V max = 30 V
I max = 104 mA
C = 6.6 nF
i
L = 0 uH
i
V max = 30 V
I max = 110 mA
C = 4.2 nF
i
L = 0 uH
i
V max = 30 V
I max = 90 mA
C = 4.2 nF
i
L = 0 uH
i
V max = 30 V
I max = 110 mA
C = 6.6 nF
i
L = 0 uH
i
V max = 30 V
I max = 96 mA
C = 3.7 nF
i
L = 0 uH
i
V max = 15.5 V
I max = 52 mA
C = 20 nF
i
L = 30 uH
i
Temperature Code
Max. Ambient
6.3.2 CSA Certification Record
Certificate:
Class 2258 04
Class I, Div 1, Groups A, B, C and D;
Class II, Div 1, Groups E, F, and G,
Class III, Div 1, Enclosure Type 4X:
Model TZIDC, P/N V18345-x0x2x2xx0x Intelligent Positioner
Input rated
Output pressure
Intrinsically safe with entity parameters of:
Terminals 11 / 12
Terminals 81 / 82
Terminals 83 / 84
Terminals 31 / 32
Terminals 41 / 42 and 51 / 52
Terminals Limit2 41 / 42 and
Limit1 51 / 52
When installed per installation Drawing No 901064
Temperature Code
Max. Ambient
IMPORTANT (NOTE)
• The "x" in P/N denotes minor mechanical variations or
optional features.
• Local communication interface LKS shall not be used in
hazardous location.
• Each pair of conductors of each intrinsic safety circuit
shall be shielded.
10/18-0.22-FR
1649904 (LR 20312)
PROCESS CONTROL
EQUIPMENT – Intrinsically
Safe, Entity – For Hazardous
Locations
30 V DC; max.4 ... 20 mA
Max. 90 psi
V max = 30 V
I max = 104 mA
C = 6.6 nF
i
L = 0 uH
i
V max = 30 V
I max = 110 mA
C = 3.7 nF
i
L = 0 uH
i
V max = 30 V
I max = 96 mA
C = 3.7 nF
i
L = 0 uH
i
V max = 30 V
I max = 110 mA
C = 6.6 nF
i
L = 0 uH
i
V max = 30 V
I max = 96 mA
C = 3.7 nF
i
L = 0 uH
i
V max = 15.5 V
I max = 52 mA
C = 20 nF
i
L = 30 uH
i
T4
85 Deg C
17
